Molex Pico-Clasp Series Right Angle Surface PCB Header, 10 Contacts, 1 mm Pitch, Single Row, Shrouded, Nylon 501568-1007

The Molex 501568-1007 Pico-Clasp Series PCB Header is a high-quality electronic connector designed specifically for wire-to-board applications that require compact, high-density interconnection. Featuring a 1 mm pitch, this right angle header accommodates 10 male contacts in a single row, optimizing signal routing in space-constrained PCB layouts.

Constructed from durable nylon for its housing and brass for the contacts, with tin plating for enhanced conductivity, the header delivers robust mechanical stability and excellent electrical performance. Its shrouded configuration protects against misalignment and ensures reliable mating with corresponding connectors, making it ideal for demanding industrial and commercial environments.

The 501568-1007 header is suitable for surface mount applications and facilitates efficient solder termination during PCB manufacturing. Operating across a temperature range from -40°C to 105°C, it is suited for a variety of electronic device and system installations, offering consistent performance in harsh conditions.

This product supports a maximum voltage of 50 V and a current rating of 1 A, catering to low-power signal and data transmission tasks on circuit boards. The male pin arrangement is designed for compatibility with Molex Pico-Clasp series wire-to-board connector systems, ensuring positive locking and secure high-density connections in critical applications.

The Molex Pico-Clasp Series header is widely used in industrial electronics, consumer devices, medical instrumentation, laboratory systems, and manufacturing control boards where reliable, compact PCB interconnection is critical. Its shrouded design enhances durability and prevents accidental unmating or alignment issues during operation.

Key features include robust nylon construction, brass contacts with tin plating, single-row 10-contact layout, right angle surface mount design, and solderable termination. Standard compliance and operational versatility make it a preferred choice for engineers and manufacturers seeking efficient PCB connectivity solutions within demanding environments.
