Molex MicroClasp Series Straight Through Hole PCB Header, 2 mm Pitch, 6 Contacts, 1 Row, Shrouded 55932-0610

Free Delivery in India | Lowest Global Shipping Charges

Molex MicroClasp Series Straight Through Hole PCB Header, 2 mm Pitch, 6 Contacts, 1 Row, Shrouded 55932-0610

Name: Molex MicroClasp Series Straight Through Hole PCB Header, 2 mm Pitch, 6 Contacts, 1 Row, Shrouded 55932-0610
Brand: Molex
SKU: 85206
Price: 0.76 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	Japan
Voltage	250V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Tin
Series	MicroClasp
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Interfaces	lance system
Number of Rows	1
Pitch	2mm
Contact Plating	Tin
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.2mm
Mating Pin Length	2mm

Key Features

Offers space savings for PCB applications with a compact 2.00 mm pitch design.
Includes unique inner positive lock for latch protection and secure retention.
Supports up to 3 A current capability per contact.
Straight through hole mounting for easy PCB integration.
Solder termination type suitable for assembly automation.
Manufactured with high-quality polyester housing material.
Wide operating temperature range from -40°C to 105°C.
Shrouded construction enhances connection security and durability.

Product Description

Molex 55932-0610 MicroClasp Series PCB Header is a compact, straight through hole connector optimized for space savings and secure wire-to-board interface in electronic and industrial systems. Featuring 6 male tin-plated contacts organized in a single row with a 2 mm pitch, this header is designed to facilitate reliable PCB connections where board space is at a premium. The shrouded construction not only protects contacts but also offers enhanced mating accuracy and mechanical stability.

The MicroClasp Series utilizes a unique inner positive lock mechanism that provides latch protection, secure retention, and an audible click upon successful mating, ensuring a dependable electrical connection. Low insertion and withdrawal forces make handling fast and efficient, ideal for high-volume assembly environments.

This header is constructed with robust polyester housing for excellent mechanical strength and electrical insulation. Solder termination and straight through hole mounting support automated PCB assembly processes. Contact plating and material choices ensure reliable performance and corrosion resistance, especially in demanding industrial environments.

Rated for up to 3 A maximum current and 250 V voltage, it supports various signal and power transmission tasks. The operating temperature range of -40°C to 105°C suits usage in both laboratory and commercial electronics, including factory automation, instrumentation, and control panels.

Key features include a two-point contact design for high-current capability, a housing lance system for terminal protection, and compatibility with wire-to-board connector systems. The shrouded design and boss aid in PCB space savings and secure mating, making it suitable for high-density board layouts.

Compact design delivers space savings for PCB mounting. Inner positive lock protects against accidental unplugging. Supports up to 3 A current per contact and 250 V rating. Wide thermal tolerance from -40°C to 105°C. Solder termination and straight mounting ideal for automation.

Shrouded body and polyester housing improve mechanical reliability. Perfect for industrial electronics, PCB assemblies, factory automation, and instrumentation.
