Samtec TSS Series Right Angle Through Hole PCB Header 10 Contacts 2.54 mm Pitch 2 Row Shrouded TSS-105-04-G-D-RA

The Samtec TSS Series TSS-105-04-G-D-RA is a high-performance right angle through hole PCB header designed for reliable board-to-board connections in advanced electronic systems. Incorporating ten phosphor bronze male pins, this shrouded header offers robust mechanical and electrical connectivity for demanding industrial and commercial applications.

With its 2.54 mm pitch arranged in two rows, the connector provides a familiar and versatile interface compatible with standard PCB header layouts. The contact plating, available in gold or tin, delivers efficient conductivity and long-term resistance to oxidation or wear. The right angle orientation makes it ideal for edge, daughterboard, or perpendicular PCB installations where space utilization and signal routing flexibility are critical.

The housing, fabricated from glass filled polyester, ensures exceptional mechanical strength as well as thermal and chemical stability, supporting continuous operation across a wide temperature span from -55°C to 125°C. The shrouded design not only aids blind mating but also enhances resistance to physical stress and connector damage, reducing the likelihood of contact misalignment during repeated mating cycles or field handling.

Installation is straightforward via solder termination, which integrates seamlessly into standard printed circuit assembly lines and guarantees secure retention in vibration-prone environments. The male pin contact gender is optimized for interface with compatible female sockets in board-to-board or board-to-cable connector systems.

The TSS-105-04-G-D-RA is engineered to support a range of professional uses, including automation control, instrumentation, laboratory electronics, embedded systems, and communication equipment assembly. The dual-row configuration and precise 2.54 mm (0.100 in) pitch supports high-density signal operation without suffering from crosstalk or mechanical interference.

Whether integrated into new designs or used as a drop-in replacement, this PCB header meets the needs of electrical engineers seeking reliable, repeatable, and manufacturable connector solutions. Its compliance with industry standards ensures broad compatibility and long-term component availability for ongoing support and field service requirements.

Discover more PCB Header solutions and connector technology within the Samtec TSS product range and browse the EnvMart Electronics Components catalogue to explore related board-level interconnect options.
