Panasonic Shielded Power Choke Coil with Metal Composite Core 6.8 μH ±20% 6.7 A Idc Surface Mount ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4.8mm |
| Length | 6.4mm |
| Model | ETQP4M |
| Depth | 4.8mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 6.8μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 6.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 35.31mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Inductance of 6.8 microhenries with ±20% accuracy.
- Maximum DC current rating of 6.7 amperes for high current applications.
- Robust metal composite core offering durability and stable magnetic properties.
- Wirewound construction with surface mount termination style.
- Shielded design minimizing electromagnetic interference.
- Operates reliably between -40°C and 150°C including self-heating conditions.
- Complies with AEC-Q200 automotive standard ensuring high reliability.
- Packaging supplied as tape and reel suitable for automated assembly.
Product Description
Panasonic ETQP4M is a shielded power choke coil featuring a metal composite core designed to deliver high reliability and durability in demanding automotive and industrial environments. It provides an inductance of 6.8 μH with a tolerance of ±20% while supporting a maximum DC current of 6.7 A, making it suitable for power management and filtering applications in electronics.
The coil is wirewound and moulded, with a surface mount termination style enabling easy PCB integration. The robust design includes shielding to reduce electromagnetic interference, enhancing performance stability. This inductor operates effectively over a broad temperature range from -40°C to 150°C, including self-heating, meeting rigorous automotive AEC-Q200 standards.
Its compact package measures 6.4 mm in length, 4.8 mm in height, and 4.8 mm in depth, with a low DC resistance of 35.31 mΩ to minimize power losses. The packaging in tape and reel format facilitates efficient automated assembly processes in manufacturing industries.
Typical industrial and automotive applications of the Panasonic ETQP4M shielded choke coil include power supply filtering, noise suppression, energy storage in switching regulators, and voltage stabilization in electronic circuits.
Inductance of 6.8 microhenries with ±20% tolerance. Maximum DC current rating of 6.7 amperes for high current capacity. Shielded construction to minimize EMI and improve signal integrity. Metal composite core delivers superior thermal and magnetic performance.
Compliance with AEC-Q200 automotive standard for demanding environments. Wirewound and moulded for mechanical robustness. Surface mount termination compatible with automated PCB assembly. Tape and reel packaging for manufacturing efficiency.
Compact size: length 6.4 mm, height 4.8 mm, depth 4.8 mm. Low DC resistance of 35.31 milliohms for high efficiency.
Explore our wide range of electronic components including Inductors at EnvMart for reliable and high-quality solutions tailored to automotive, industrial, and electronic manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance of this power choke coil is 6.8 microhenries with a tolerance of ±20%.
It has a maximum DC current rating of 6.7 amperes, suitable for high current applications.
This model operates reliably between -40°C and 150°C, including self-heating conditions.
The choke coil features a robust metal composite core, which provides durability and stable magnetic properties.
It is supplied in tape and reel packaging, which is suitable for automated assembly processes.
The dimensions of this model are 6.4 mm in length, 4.8 mm in height, and 4.8 mm in depth.
The maximum DC resistance is 35.31 milliohms, which helps minimize power losses.
Yes, it complies with the AEC-Q200 automotive standard, ensuring high reliability in demanding environments.
This model features a surface mount termination style, allowing for easy integration onto PCBs.
It is constructed using a wirewound method, which contributes to its mechanical robustness.
This choke coil complies with RoHS standards, ensuring it meets environmental regulations.
Typical applications include power supply filtering, noise suppression, and voltage stabilization in electronic circuits.
