Samtec TFM Series Right Angle Through Hole PCB Header 6 Contacts 1.27 mm Pitch 2 Rows Shrouded TFM-103-01-L-D-RE1-WT

Free Delivery in India | Lowest Global Shipping Charges

Samtec TFM Series Right Angle Through Hole PCB Header 6 Contacts 1.27 mm Pitch 2 Rows Shrouded TFM-103-01-L-D-RE1-WT

Name: Samtec TFM Series Right Angle Through Hole PCB Header 6 Contacts 1.27 mm Pitch 2 Rows Shrouded TFM-103-01-L-D-RE1-WT
Brand: Samtec
SKU: 84539
Price: 3.45 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Samtec
Orientation	Right Angle
Current	3.2A
Model	TFM-103-01-L-D-RE1-WT
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TFM
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board

Key Features

Designed for board-to-board connections requiring right angle orientation.
Features 6 male pin contacts arranged in 2 rows.
Maintains a compact 1.27 mm pitch for dense PCB layouts.
Equipped with a shrouded housing made of liquid crystal polymer for durability.
Contact terminals are plated with gold to ensure reliable conductivity.
Suitable for solder termination in through hole mount applications.
Rated for a maximum current of 3.2A and voltage up to 250V.
Operates within a wide temperature range from -55°C to 125°C.

Product Description

The Samtec TFM-103-01-L-D-RE1-WT header is a specialised PCB connector, ideal for demanding electronic applications requiring compact, robust and reliable board-to-board interfaces. This right angle through hole model features 6 male pin contacts, divided into two rows, with a dense 1.27 mm pitch.

The shrouded housing is constructed from liquid crystal polymer, offering enhanced mechanical strength, thermal resistance and chemical stability for harsh environments. The gold-plated contacts assure excellent electrical conductivity and corrosion resistance, making it suitable for signal or power circuit integration.

Installation is facilitated through standard solder termination, supporting secure placement in a variety of through hole PCB designs. The connector is intended for board-to-board systems, supporting elevated connections where space optimization and robust mating are critical.

This header is rated to handle currents up to 3.2A and voltages up to 250V, with an operating temperature range from -55°C to 125°C, ensuring reliable performance in industrial, automation, instrumentation, and advanced electronic control applications.

The two-row configuration supports effective signal routing and reduces cross-talk, while the right angle orientation helps in managing PCB layout constraints. Its unshrouded counterpart may be preferable where less robust protection is needed; this shrouded model excels in scenarios where connector stability and connector guide accuracy are essential.

Board-to-board connection for industrial, automation, instrumentation, or consumer electronics. High-density PCB layouts benefit from the 1.27 mm pitch and right angle configuration. Reliable connectivity due to gold plating and robust housing material.

Solder termination ensures secure and robust mechanical assembly. Ideal for circuit boards in products such as controllers, analyzers, machine interfaces, sensors, and more.

Samtec's TFM Series offers proven solutions for compact PCB designs. For more options in PCB Header connectors and the complete Samtec range, browse the Electronics & Electricals category on EnvMart.
