Samtec Vertical Surface PCB Header , 60 Contacts, 0.8 mm Pitch, 2 Row, Shrouded, 1.4A ERM8
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 318V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 1.4A |
| Model | ERM8 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | ERM8 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 0.8mm |
| Contact Plating | Gold |
| Number of Contacts | 60 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- High-quality vertical surface mount PCB header suitable for board-to-board connections.
- Features 60 male contacts with 0.8 mm pitch for high-density applications.
- Shrouded design provides secure and reliable mating for system interconnects.
- Constructed from liquid crystal polymer with phosphor bronze contacts and gold plating for durability.
- Supports 318V voltage and 1.4A current, ideal for high-performance electronic systems.
- Operating temperature range from -55°C to 125°C for demanding environments.
- Edge rate contact system designed for high-mating cycles and 56Gbps PAM4 performance.
- Solder termination for robust surface mount installation.
Product Description
The Samtec ERM8-030-09.0-L-DV-TR is a vertical surface PCB header engineered for advanced board-to-board interconnections in electronic systems. Featuring a high-density configuration with 60 contacts arranged in two rows and a compact 0.8 mm pitch, this header is optimized for applications requiring both space efficiency and electrical performance.
Designed with a shrouded housing, the ERM8-030-09.0-L-DV-TR ensures secure mating and enhanced reliability, mitigating misalignment and potential contact wear. The housing is made from liquid crystal polymer (LCP), providing excellent mechanical strength and heat resistance. Phosphor bronze contact material, finished with gold plating, delivers superior conductivity and wear life, supporting sustained performance even under frequent mating cycles.
This PCB header supports a voltage rating of 318V and a current rating of 1.4A, making it suitable for high-speed and high-power requirements. The edge rate contact system enables high mating cycles and supports up to 56Gbps PAM4 signaling, meeting the needs of advanced digital communication systems.
The device operates reliably across a wide temperature range from -55°C to +125°C, accommodating diverse industrial and laboratory environments. Its solder termination and surface mount form factor ensure robust and stable installation on PCBs, facilitating integration into manufacturing workflows.
With a board-to-board connector system, this header is ideal for industrial electronics, instrumentation, automation controls, telecommunications, and commercial electronic assemblies where compact size and high reliability are paramount.
Key industrial use cases include manufacturing automation, process control instrumentation, test and measurement systems, communication infrastructure, and laboratory equipment.
EnvMart offers browseable categories for PCB Headers, Connectors, and associated electronic components for comprehensive project requirements. Explore leading brands like Samtec for additional industrial connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this model is 318V, making it suitable for high-speed and high-power applications.
This PCB header supports a current rating of 1.4A, which is ideal for various electronic systems.
It features a compact 0.8 mm pitch with a total of 60 male contacts arranged in two rows.
The housing is made from liquid crystal polymer, while the contacts are constructed from phosphor bronze and finished with gold plating for enhanced conductivity.
This model operates reliably within a temperature range of -55°C to +125°C, accommodating various environmental conditions.
It uses a solder termination type, ensuring a robust and stable installation on PCBs.
This PCB header is designed for a board-to-board connector system, making it suitable for advanced interconnections.
The shrouded design of this header provides secure mating and reduces the risk of misalignment during connections.
It has 2 rows of contacts, allowing for a high-density configuration.
The edge rate contact system is engineered for high-mating cycles and supports up to 56Gbps PAM4 performance.
It is ideal for use in industrial electronics, instrumentation, automation controls, telecommunications, and commercial electronic assemblies.
This PCB header is manufactured in India.
