Samtec Straight Through Hole PCB Socket, 6-Contact, 2 Row, 2.54 mm Pitch, Board-to-Board, Solder, BCS-103-S-D-PE-BE

The Samtec BCS-103-S-D-PE-BE belongs to the BCS series of PCB Sockets, built for board-to-board interconnections in electronic systems. This model offers a straight, through-hole configuration, enabling straightforward integration into printed circuit boards where robust connectivity is critical.

Equipped with 6 phosphor bronze contacts, this socket ensures reliable conductivity and signal transmission, making it suitable for industrial and laboratory electronic applications. The 2-row arrangement with a 2.54 mm pitch complies with industry-standard spacing, offering compatibility with various electronic designs. The solder-type termination provides solid mounting and electrical contact, reducing risk of intermittent connections.

The housing is composed of black liquid crystal polymer, delivering strong thermal resistance and mechanical stability. Operating within a temperature range from -55°C to 125°C, it is well-suited for high-performance, temperature-sensitive environments such as manufacturing, instrumentation, and control equipment.

The straight orientation is ideal for through-hole mounting, streamlining assembly and maintenance procedures. Each contact has a current rating of up to 4.6A, supporting applications where higher power handling is required.

Contact material is phosphor bronze, plated with gold over tin to enhance durability, conductivity, and resistance to corrosion or oxidization. The socket satisfies RoHS compliance requirements, signifying adherence to modern environmental and safety standards.

Typical use cases include industrial, laboratory, automation, and electronic device manufacturing, where secure PCB interconnections are essential for system functionality and reliability.

Designed for board-to-board connections in PCB systems. Provides 6 phosphor bronze contacts for reliable signal integrity. Features a 2-row configuration with 2.54 mm pitch for standardized spacing. Termination style is solder for secure mounting and operation.

Black liquid crystal polymer housing ensures durability and heat resistance. Straight orientation allows for efficient through-hole mounting. Supports up to 4.6A per pin, suitable for high-current applications. Operating temperature range from -55°C to +125°C, ideal for demanding environments.
