Molex 52465 Series Straight Surface PCB Socket, 10 Contacts, 2 Rows, 0.8 mm Pitch, Surface Mount, Solder 52465-1071-TR250

Molex 52465-1071-TR250 is a straight surface mount PCB socket designed to provide secure board-to-board electrical connections in a wide range of electronic devices. With a compact, dual-row layout and 10 contacts spaced at a precise 0.8 mm pitch, this connector is engineered for high-density PCB designs and automation systems, meeting the needs of signal transfer and mechanical interfacing.

The housing is crafted from durable thermoplastic, offering robust mechanical strength and heat resistance. The contacts are made from phosphor bronze with a reliable tin-plated finish. This combination delivers superior conductivity, reliability, and resistance to wear and corrosion during repeated mating cycles - up to 30 cycles as specified.

The connector is rated for up to 500mA of electrical current and can operate at voltages up to 50V, making it versatile for both signal and board-to-board power applications. Its straight orientation and surface mount design allow for efficient automated PCB assembly, while the solder termination ensures solid electrical contact and mechanical stability.

Operating temperature ranges from -40°C to 105°C, enabling its use in harsh environments such as industrial control systems, consumer electronics, and automation equipment. The female contact configuration ensures reliable mating and connection integrity during repeated use.

Typical applications include interfacing between PCBs in mechanical assemblies, board-to-board signal transfer, signal routing for automated machinery, and high-density circuit layouts in consumer devices such as instrumentation, control boards, and communication modules. The recommended PCB thickness for optimal performance is 1.60 mm.

This PCB socket is commonly used in industrial, electronics manufacturing, laboratory and commercial automation sectors, allowing for easy integration into modern electronic assemblies. Browse the Molex PCB Socket category on EnvMart for compatible connectors and variant options.
