RIGOL High-Resolution Digital Oscilloscope MHO2000 Series
Model
Analog Bandwidth
Max Sample Rate
Analog Channels
Max Memory Depth
Specifications
| Country of Origin | India |
|---|---|
| Display | 10.1-inch, 1280x800 HD capacitive multi-touch |
| Brand | Rigol |
| Power Supply | AC 100 V to 240 V, 50 Hz to 60 Hz |
| Operating Temperature | -10°C to +50°C |
| Dimensions | 335 x 235 x 154 mm |
| Memory | 128 GB internal storage |
| Connectivity | USB 3.0, LAN, HDMI |
| Model | MHO2000 Series |
| Operating System | Android |
| Weight | 5.3 Kg |
| Bandwidth | Up to 350 MHz |
| Sampling rate | Up to 2 GSa/s |
| Max Power | 400 VA |
| Input Impedance | 1 MΩ ±1% / 50 Ω ±1% |
| Waveform Capture Rate | 1,000,000 wfms/s (record) |
| Vertical Resolution | 12-bit (up to 16-bit in High Resolution mode) |
| Memory Depth | 500 Mpts (half-channel), 250 Mpts (full-channel) |
| Bandwidth Limit | 20 MHz / 250 MHz / Full |
| Product Condition | New |
| MPN | MHO2000 Series |
| Analog Channels | 4 + 1 EXT Trigger |
| Vertical Sensitivity (1 MΩ) | 200 μV/div to 10 V/div |
| Vertical Sensitivity (50 Ω) | 200 μV/div to 1 V/div |
| Recommended Calibration Interval | 18 months |
| Rise Time (typical) | As low as 1.4 ns |
| Input Capacitance | 19 ±3 pF |
| ESD Protection | ±8 kV |
| Maximum Input Voltage (1 MΩ) | CAT I 300 Vrms |
| Standard Digital Channels | 16 (D0–D15) |
| Arbitrary/Function Generator | 2 ch (optional), 50 MHz, 1 GSa/s |
Key Features
Rigol MHO2000 Series high-resolution 4-channel digital oscilloscope with up to 350 MHz bandwidth, 2 GSa/s sampling, 12-bit resolution, and 10.1-inch touch display delivers superior signal analysis for advanced electronic measurements.
- Equipped with 4 analog channels and 1 external trigger for multi-signal monitoring.
- Provides up to 350 MHz bandwidth and 2 GSa/s real-time sampling for high-speed signal capture.
- Features 12-bit vertical resolution, extendable to 16-bit for high resolution mode for precise measurements.
- Comes with a large 10.1-inch 1280x800 capacitive multi-touch display for enhanced usability.
- Supports up to 500 Mpts memory depth and high waveform capture rates up to 1,000,000 wfms/s.
- Includes advanced trigger types, serial decoding, and optional 2-channel 50 MHz arbitrary/function generator.
- Standard 16 digital channels (with logic probe) and USB, LAN, HDMI connectivity.
- Android operating system with 128 GB internal storage for flexible data management.
- Ideal for embedded design, power electronics, automotive testing, and precise signal analysis.
- Integrated battery pack and robust portability for on-site and laboratory applications.
Product Description
Rigol MHO2000 Series high-resolution digital oscilloscope features a 4-channel analog system with bandwidth up to 350 MHz and 2 GSa/s real-time sampling, making it a powerful instrument for advanced signal analysis in laboratory and industrial applications. With 12-bit vertical resolution (expandable to 16-bit in high-resolution mode), it captures fine signal details, while 500 Mpts of memory and up to 1,000,000 wfms/s capture rate ensure you do not miss critical events. The 10.1-inch HD capacitive touch display enhances viewing and operation efficiency.
- 4 analog channels plus 1 external trigger support.
- Bandwidth up to 350 MHz, rise time as low as 1.4 ns.
- 2 GSa/s maximum real-time sampling rate and 500 Mpts memory depth.
- 12-bit/16-bit vertical resolution for exceptional detail and measurement accuracy.
- Standard 16 digital channels (logic analyzer functionality) and advanced triggering including I2C, SPI, CAN, UART, and more.
- Extensive measurements and analysis including FFT, histogram, pass/fail testing, and waveform search.
- Optional 2-channel 50 MHz arbitrary/function generator for embedded test flexibility.
- Robust Android OS, 128 GB internal storage, plus USB, LAN, HDMI outputs.
- Battery pack support allows extended remote or field operation.
- Safety: ±8 kV ESD protection, CAT I 300 V analog input rating (1 MΩ), and max 5 Vrms (50 Ω).
Applications include R&D, manufacturing, embedded system debugging, automotive electronics, industrial automation, and education. The Rigol MHO2000 Series is engineered for high fidelity measurement, advanced analysis, and modern workflow integration.
