RS PRO Toggle Switch, PCB Mount, On-Off-On Operation, DPDT, Solder Terminal, Brass Actuator, 250V AC, 12A, IP68, 206-6976

RS PRO 206-6976 Toggle Switch is a DPDT (double pole double throw) switch engineered for PCB mounting applications. It features an On-Off-On switch operation and solder terminal type, delivering reliable electrical switching for industrial environments. The switch is designed with a brass actuator measuring 17mm in length and a body made from durable nylon 66 and aluminium die-casting alloy providing mechanical robustness.

This toggle switch supports a contact current of 12A and an AC voltage rating of 250V, suitable for various electric motor and actuator controls where polarity reversal is needed. The device offers a high level of protection with an IP68 front panel seal, ensuring resistance against dust and water ingress. It operates efficiently over a broad temperature range from -30°C to +85°C, making it suitable for harsh industrial and outdoor conditions.

The switch adheres to international standards including RoHS, UL, and cUL certifications, providing compliance assurance. Measuring 28.7mm in length, 15.7mm in width, and a height of 64.2mm, it fits well in compact circuit designs. Its mechanical life expectancy is rated at 10 cycles, ensuring durable operation under typical industrial use.

Applications include telecommunications systems, aerospace components, automotive electronics, instrumentation control, and various industrial control solutions. The sealed design and double pole double throw configuration make this toggle switch ideal for switching motor directions and controlling electrical actuators.

Features a double pole double throw (DPDT) contact configuration. Rated for 250V AC contact voltage and 12A contact current. Equipped with a brass actuator and solder terminal type for secure connections. Provides IP68 front panel protection ensuring sealed electrical operation.

Operates reliably within a temperature range of -30°C to +85°C. Compact dimensions with a length of 28.7mm, width of 15.7mm, and height of 64.2mm. Constructed with durable materials including brass, aluminium die-casting, and nylon body.

Complies with RoHS, UL, and cUL standards for quality assurance. Mechanical life is rated at 10 cycles ensuring longevity in industrial settings. Ideal for applications in telecommunications, aerospace, automotive, and industrial control solutions.

Choose RS PRO Toggle Switches for reliable, durable, and precise switching solutions in your industrial and commercial projects. Explore more electronics and electrical components on EnvMart.
