ABB Fuse Switch Disconnector 2-Pole Enclosed Base Mount 690V 250A OS250B04N2K 1SCA022763R6280

Free Delivery in India | Lowest Global Shipping Charges

ABB Fuse Switch Disconnector 2-Pole Enclosed Base Mount 690V 250A OS250B04N2K 1SCA022763R6280



Category Fuse Switch Disconnector Brand ABB Condition New

Specifications

Country of Origin	Finland
Brand	ABB
Model	1SCA022763R6280
Mount Type	Base
Series	OS250B04N2K
Switching Current	250A
Terminal type	Lug Terminal
Number of Poles	2
Standards/Approvals	IEC 60947-3
Switching Voltage	690V
Switching Power	23W
Mechanical Fuse Size	B1-B4
Enclosed/Not Enclosed	Enclosed
Fuse Current	250A

Key Features

Provides reliable disconnection with a switching voltage rating of 690V.
Rated for switching current and fuse current of 250A for high power circuits.
Features lug type terminals with 25 mm width for secure connections.
Enclosed construction ensures safety and compliance with IEC 60947-3 standards.
Utilizes mechanical fuse sizes B1 to B4 for compatible fuse replacements.
Operated by a direct mounted handle and base mounted for stable installation.
Includes a fourth pole switched with solid link on the right side for enhanced control.
Switching mechanism code 04 located on the left side for operational precision.

Product Description

ABB 1SCA022763R6280 Fuse Switch Disconnector is a 2-pole enclosed switch designed for industrial and electrical automation applications requiring reliable disconnection with a switching voltage of 690V and switching current of 250A.

This base mounted fuse switch employs a British Standard fuse system with mechanical fuse sizes ranging from B1 to B4, allowing straightforward fuse replacements. It features lug type terminals with a width of 25 mm, ensuring robust electrical connections and efficient current transfer.

The device is equipped with a direct mounted handle for easy operation and a solid linked fourth pole located on the right side, adding flexibility for complex switching configurations. Its switching operating mechanism code 04 is positioned on the left side, enabling precise switching actions. Line terminals can be connected either at the top in-bottom out or bottom in-top out, providing adaptability in installation.

Constructed with safety in mind, the fuse switch disconnector meets IEC 60947-3 standards and is enclosed to prevent accidental contact, making it suitable for demanding industrial environments including automation, manufacturing, and electrical distribution systems.

Provides reliable disconnection with a switching voltage rating of 690V. Rated for switching current and fuse current of 250A for high power circuits. Features lug type terminals with 25 mm width for secure connections. Enclosed construction ensures safety and compliance with IEC 60947-3 standards.

Utilizes mechanical fuse sizes B1 to B4 for compatible fuse replacements. Operated by a direct mounted handle and base mounted for stable installation. Includes a fourth pole switched with solid link on the right side for enhanced control.

Switching mechanism code 04 located on the left side for operational precision. Line terminals positioned for versatile top in-bottom out or bottom in-top out configurations. Manufactured in Finland, assuring quality and durability.

This ABB fuse switch disconnector is ideal for electrical control and protection in industrial, manufacturing, and commercial power systems. It offers robust performance and ease of maintenance for system integrators and electrical professionals.
