ABB Fuse Switch Disconnector Enclosed 4-Pole 63A Switching Voltage 690V AC Power 55kW 1SCA115567R1001

ABB 1SCA115567R1001 Fuse Switch Disconnector is an enclosed, base-mounted switch designed for safe and reliable electrical circuit disconnecting and protection. This switch disconnector offers a 4-pole configuration supporting up to 63 amperes of fuse current, suitable for industrial and commercial electrical installations. The device operates at a switching voltage of up to 690V AC and a maximum switching power of 55kW, making it ideal for medium-power applications.

The switch uses a DIN fuse system and is operated from the front, facilitating ease of maintenance and installation. It comes with screw-type terminals that must be tightened with torques of 3 N·m and 4 N·m to ensure robust electrical contacts, supporting long-term safety and operational stability.

The fourth pole is located on the left side and uses a solid link switched type, enhancing the device’s switching reliability and functional versatility. Note that the handle and shaft are not included, so these components need to be sourced separately depending on the installation requirements.

Designed with a pollution degree rating of 3, this fuse switch disconnector is well suited for challenging industrial environments where contamination can be present. The unit is manufactured in Finland, adhering to high quality standards even though specific certifications and approvals are not listed.

Applications include use in electrical distribution panels, automation systems, and industrial machinery as a reliable means to isolate and protect circuits. Its enclosed configuration offers protection against accidental contact and environmental factors.

Equipped with 4 poles for comprehensive circuit control. Enclosed type design ensures safe operation and protection. Supports fuse current rating of 63A for reliable circuit protection. Operates with a switching voltage up to 690V AC and switching power of 55kW.

Features screw type terminals with tightening torque of 3 N·m and 4 N·m for secure connections. Fourth pole positioned on the left side with solid link switched type. Handle and shaft are not included, requiring separate procurement as needed.

Designed with pollution degree 3 for industrial environmental suitability. Explore more Fuse Switch Disconnectors and electrical switchgear on EnvMart to find compatible components and accessories for your industrial and commercial projects.
