Texas Instruments Operational Amplifier, 1 MHz Gain Bandwidth, 8-Pin 5.5V SOT-23 Package OPA2348AIDCNR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.1mm |
| Length | 2.9mm |
| Model | OPA2348AIDCNR |
| Width | 1.63mm |
| Mount Type | Surface |
| Series | OPA2348 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | ±10 pA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.5V/μs |
Key Features
- Designed for surface mount with SOT-23 package type.
- Dual channel operational amplifier with 8 pins.
- Operates over a supply voltage range of 3V to 5.5V.
- Gain bandwidth product of 1 MHz suitable for signal conditioning.
- Typical slew rate of 0.5 V/μs ensures smooth signal transitions.
- Low input bias current of ±10 pA for high precision applications.
- Input offset voltage typically 6 mV minimizes error voltages.
- Wide operating temperature range from -40°C to 125°C.
Product Description
Texas Instruments OPA2348AIDCNR is a high-performance CMOS operational amplifier designed for use in low power, high precision signal conditioning applications. Featuring a gain bandwidth product of 1 MHz and housed in a compact 8-pin SOT-23 surface mount package, this dual channel device operates efficiently over a supply voltage range from 3V up to 5.5V. It is optimized for industrial and automotive applications requiring robust operating conditions.
This operational amplifier exhibits a typical slew rate of 0.5 V/μs, which enables swift and stable response to input signals, making it suitable for filtering and amplification tasks in instrumentation, data acquisition, and control systems. The input bias current is exceptionally low at ±10 picoamperes, contributing to high input impedance and low offset errors, with an input offset voltage around 6 mV for precise analog signal processing.
Operating over a wide temperature range from -40°C to 125°C, the OPA2348AIDCNR meets stringent automotive standard AEC-Q100, ensuring reliability in demanding environments such as automotive electronics, industrial controls, and communication devices. Its small form factor with dimensions approximately 2.9mm length, 1.63mm width, and 1.1mm height allows integration into densely packed printed circuit boards.
The device’s packaging supports automated assembly processes, making it ideal for high-volume manufacturing. This operational amplifier is widely used in industrial instrumentation, automotive sensor interfaces, portable instrumentation, and other electrical systems requiring stable and accurate amplification with minimal power consumption.
Designed for surface mount with SOT-23 package type. Dual channel operational amplifier with 8 pins. Operates over a supply voltage range of 3V to 5.5V. Gain bandwidth product of 1 MHz suitable for signal conditioning. Typical slew rate of 0.5 V/μs ensures smooth signal transitions.
Low input bias current of ±10 pA for high precision applications. Input offset voltage typically 6 mV minimizes error voltages. Wide operating temperature range from -40°C to 125°C. Meets automotive standard AEC-Q100 for reliable automotive use.
Explore more Operational Amplifiers and semiconductor components on EnvMart for industrial, automotive, and electronic design applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1 MHz, making it suitable for signal conditioning applications.
It operates over a supply voltage range from 3V to 5.5V.
The typical slew rate is 0.5 V/μs, which ensures smooth signal transitions.
The input bias current is ±10 pA, contributing to high precision in applications.
The input offset voltage is typically 6 mV, which helps minimize error voltages.
The dimensions are approximately 2.9 mm in length, 1.63 mm in width, and 1.1 mm in height.
It operates over a wide temperature range from -40°C to 125°C.
This model meets the AEC-Q100 automotive standard, ensuring reliability in automotive applications.
It is a dual channel operational amplifier, featuring 2 channels.
It is designed in a SOT-23 surface mount package type.
Yes, its packaging supports automated assembly processes, making it ideal for high-volume manufacturing.
This operational amplifier is widely used in industrial instrumentation, automotive sensor interfaces, and portable instrumentation.
