Vishay 2225 Shielded Surface Mount Inductor with Metal Composite Core 3.3 μH ±20% 9.2 A Idc IHLP3232DZER3R3M01
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 4mm |
| Length | 8mm |
| Model | IHLP3232DZER3R3M01 |
| Depth | 4mm |
| Series | IHLP |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 3.3μH |
| Standards/Approvals | RoHS, JEDEC |
| Package/Case | 2225 |
| Maximum DC Current | 9.2A |
| Maximum DC Resistance | 17.7mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 25MHz |
| Inductor Construction | Shielded |
Key Features
- Inductor designed with a metal composite core for optimal performance.
- Constructed with a shielded design to minimize electromagnetic interference.
- Inductance tolerance of ±20% to accommodate various circuit requirements.
- Supports a maximum operating temperature of 125°C, suitable for demanding environments.
- Surface mount termination style enables easy PCB integration.
- Compact 2225 package size with dimensions 8mm length, 4mm height, and 4mm depth.
- Maximum DC resistance of 17.7 milliohms ensures high current capability.
- Compliant with RoHS and JEDEC standards for quality assurance.
Product Description
Vishay IHLP3232DZER3R3M01 shielded Surface Mount Inductor with a metal composite core provides a stable inductance value of 3.3 μH at ±20% tolerance, making it suitable for various electronic circuits requiring high current handling and low noise interference.
The device supports a maximum DC current of 9.2 A and maintains functionality within an operating temperature range from -55°C to 125°C, ensuring reliability in industrial, automotive, and consumer electronics applications.
This inductor features a shielded construction that minimizes electromagnetic interference and buzz noise through its composite core design. It is molded and compliant with RoHS and JEDEC standards, affirming its environmental and quality credentials.
The 2225 package size with precise dimensions of 8mm length, 4mm height, and 4mm depth accommodates space-efficient circuit layouts. Its surface mount termination style simplifies PCB assembly in automated manufacturing environments.
Typical uses include power supply filtering, voltage regulation, energy storage, and noise suppression in industrial electronics, telecommunications, automotive, and aerospace systems.
Metal composite core ensures high transient current handling with minimal saturation. Shielded design reduces buzz noise and electromagnetic interference in sensitive circuits. Wide operating temperature range enhances durability in extreme conditions.
Compact footprint supports miniaturized electronic device designs. Environmental compliance supports sustainable manufacturing practices.
This Vishay inductor model IHLP3232DZER3R3M01 forms part of the IHLP series, recognized for high efficiency and robust performance in surface mount applications. Browse additional electronic component categories at EnvMart for comprehensive sourcing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 3.3 μH with a tolerance of ±20%.
It supports a maximum DC current of 9.2 A, ensuring high current capability for various applications.
The dimensions of the 2225 package are 8mm in length, 4mm in height, and 4mm in depth.
The maximum operating temperature is 125°C, making it suitable for demanding environments.
This inductor features a metal composite core and has a shielded construction to minimize electromagnetic interference.
It is compliant with RoHS and JEDEC standards, ensuring quality and environmental safety.
The maximum DC resistance is 17.7 milliohms, which contributes to its high current handling capability.
The minimum operating temperature is -55°C, allowing it to function reliably in extreme conditions.
It utilizes a surface mount termination style, which simplifies PCB assembly in automated manufacturing.
The maximum self-resonant frequency is 25 MHz, suitable for various electronic applications.
Typical applications include power supply filtering, voltage regulation, energy storage, and noise suppression in various electronic systems.
This inductor is part of the IHLP series, recognized for its efficiency and performance in surface mount applications.
