Vishay 10μH ±20 % 2.3 A Idc Shielded Surface Mount Inductor with Metal Composite Core IHLP2020BZER100M01

Vishay IHLP2020BZER100M01 is a shielded surface mount inductor featuring a metal composite core with an inductance of 10μH and a tolerance of ±20%. This inductor supports a maximum DC current of 2.3A, making it suitable for power applications requiring high saturation currents.

The 2020 package ensures compact size with dimensions of 5.4mm in length, 2mm in height, and 2mm in depth. The shielded construction reduces electromagnetic interference, while the composite core design minimizes buzz noise during operation. The device operates reliably in a temperature range from -55°C to 125°C.

This inductor exhibits a low DC resistance of 199mΩ, contributing to efficient power management in electronic circuits. It is moulded for enhanced mechanical stability and meets RoHS and JEDEC compliance standards, ensuring environmental and industrial quality requirements.

Typical applications include industrial electronics, power supplies, telecommunications, and automotive electronics where space-saving and performance reliability are critical. Metal composite core provides high saturation current handling.

Shielded construction minimizes electromagnetic interference. Inductance tolerance is ±20%, ensuring stable performance. Designed for surface mount applications with a 2020 package case. Maximum operating temperature up to 125°C suitable for harsh environments.

Low DC resistance of 199mΩ reduces power losses. Complies with RoHS and JEDEC standards for environmental safety and quality. Minimum operating temperature down to -55°C for wide temperature range. Moulded design enhances durability and noise suppression.

This Vishay inductor IHLP2020BZER100M01 is an essential component in high-frequency electronic circuits and power conversion systems. Explore more Surface Mount Inductors and other Vishay products on EnvMart.
