Texas Instruments Operational Amplifier 1 MHz Gain Bandwidth, 5-Pin SOT-23 Package LM321MFX/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.45mm |
| Length | 3.05mm |
| Model | LM321MFX/NOPB |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | LM321 |
| Output Current | 20mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Maximum Supply Voltage | 30V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 500 nA |
| Vos - Input Offset Voltage | 9 mV |
| Slew Rate | 0.4V/μs |
| Input Offset Current | 150 nA |
Key Features
- Operates with a supply voltage range of 3 V to 30 V for flexible circuit design.
- Features a low input offset voltage of 9 mV ensuring accurate signal amplification.
- Includes a slew rate of 0.4 V/μs suitable for moderate speed applications.
- Designed for temperatures ranging from -40°C to 85°C, suitable for various operating environments.
- Compact dimensions of approximately 3.05 mm length, 1.75 mm width, and 1.45 mm height optimize PCB space.
- Provides an output current capability of 20 mA for driving loads efficiently.
- RoHS compliant ensuring adherence to environmental standards.
- Single channel device with 5 pins in a surface mount package for easy integration.
Product Description
The Texas Instruments LM321MFX/NOPB is a high-performance operational amplifier optimized for applications requiring a gain bandwidth of 1 MHz. This precision amplifier is housed in a compact 5-pin SOT-23 surface-mount package, making it ideal for compact electronic circuit designs with space constraints.
Operating from a minimum supply voltage of 3 V up to a maximum of 30 V, the LM321MFX/NOPB offers flexibility for low and high voltage applications alike. It maintains a low input offset voltage of 9 mV, which supports high accuracy in signal amplification tasks. With an input bias current of 500 nA and input offset current of 150 nA, signal integrity and amplifier stability are ensured.
The device withstands operating temperatures from -40°C to 85°C, supporting use in industrial, automotive (non-automotive standard), and commercial electronics. Its slew rate of 0.4 V/μs contributes to good transient response in moderate frequency applications. The physical dimensions of 3.05 mm length, 1.75 mm width, and 1.45 mm height facilitate integration into compact PCBs.
Capable of delivering output currents up to 20 mA, this operational amplifier can drive medium loads effectively. It complies with RoHS environmental directives, ensuring it meets current European standards for hazardous substances.
This single-channel, 5-pin operational amplifier is primarily used in signal conditioning, filtering, and amplification tasks within industrial electronics, instrumentation, and electrical equipment. The SOT-23 package further assists manufacturers and designers aiming for miniaturized devices.
Choose the Texas Instruments LM321MFX/NOPB for reliable, compact, and efficient operational amplifier performance suitable for a wide range of electronics design requirements. Surface-mount mount type in SOT-23 package for small footprint.
1 MHz gain bandwidth product for precision amplification. Wide supply voltage range of 3 V to 30 V. Low input offset voltage and currents enhance accuracy. Wide operating temperature from -40°C to 85°C. Output current capacity of 20 mA suitable for medium loads.
RoHS compliant for environmentally responsible design. Compact dimensions fit tightly in space-constrained applications. Single channel, 5 pin configuration for simple integration. Explore more electronic components and Operational Amplifiers at EnvMart for your industrial, laboratory, and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1 MHz, making it suitable for precision amplification tasks.
It operates with a supply voltage range of 3 V to 30 V, allowing for flexibility in various circuit designs.
The dimensions of this model are approximately 3.05 mm in length, 1.75 mm in width, and 1.45 mm in height, which helps optimize PCB space.
It can deliver an output current of up to 20 mA, suitable for driving medium loads efficiently.
The input offset voltage is 9 mV, which contributes to its accuracy in signal amplification.
This operational amplifier is designed to operate within a temperature range of -40°C to 85°C, making it suitable for various environments.
It features a slew rate of 0.4 V/μs, which is suitable for moderate speed applications.
This model is a single-channel device, designed for simple integration into circuits.
It is housed in a 5-pin SOT-23 surface-mount package, which is compact and facilitates easy integration.
The LM321MFX/NOPB is RoHS compliant, ensuring it adheres to environmental standards regarding hazardous substances.
The input bias current is 500 nA, which helps maintain signal integrity and amplifier stability.
It is primarily used in signal conditioning, filtering, and amplification tasks within industrial electronics and instrumentation.
