TDK Film Capacitor 12 nF 600 V AC 1.6 kV DC Through Hole 2 Pins B32672L1123J000

TDK B32672L1123J000 Film Capacitor is a high-quality electronic passive component utilizing metallized polypropylene film technology. It features a capacitance of 12 nF suitable for demanding AC and DC voltage environments, rated at 600 V AC and 1.6 kV DC. Designed with through-hole mounting and dual pin configuration, it offers reliable electrical insulation and mechanical stability.

This capacitor series B32671L to B32673L benefits from epoxy resin sealing that ensures resistance to environmental stress and mechanical damage. Its compact body size - 18mm length, 12mm height, and 6mm width - enables integration into space-constrained printed circuit boards.

Engineered for high peak voltage tolerance and excellent high-frequency AC load performance, these capacitors provide superior pulse withstand capability, making them robust under transient electrical conditions. With a maximum operating temperature of 125°C and compliance with automotive standard AEC-Q200 Rev D, it is suitable for use in automotive and industrial electronics.

The component meets international standards including RoHS and UL certifications, underscoring its safety and environmental friendliness. The 15 mm lead pitch and 0.8 mm lead diameter facilitate secure PCB mounting and reliable electrical connections.

Commonly utilized in electronic ballasts, resonant circuits, switched mode power supplies, and pulse circuits, these film capacitors deliver stable performance in high-frequency applications. Halogen-free options are offered upon request for environmentally sensitive projects.

Constructed using wound metallized polypropylene film technology with epoxy resin sealing. Capable of withstanding very high AC voltages across all frequency ranges. Compact dimensions measuring 18 mm length, 12 mm height, and 6 mm width.

Features a durable lead pitch of 15 mm and lead diameter of 0.8 mm. Rated for maximum operating temperature up to 125°C and meeting automotive standard AEC-Q200 Rev D. Complies with RoHS and UL standards for safety and environmental compliance.

Excellent pulse withstand capability and suitable for high-frequency AC loads and pulse circuits. Suitable for applications including electronic ballasts, switched mode power supplies, and resonant circuits. Halogen-free variants are available upon request.
