Panasonic PhotoMOS Series Solid State Relay 0.15 A Load Surface Mount 25 V Load AQY221N3T
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 2.9mm |
| Length | 2.1mm |
| Model | AQY221N3T |
| Width | 1.8mm |
| Mount Type | Surface |
| Output type | MOSFET |
| Series | PhotoMOS |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Capacitance | 1.5pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Through Hole |
| Switching Function | AC/DC Switching |
| Maximum Load Current | 0.15A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 25V |
| Minimum Load Voltage | 15V |
| Off State Leakage Current | 10nA |
| On State Resistance | 7.5Ω |
| The Panasonic VSSOP type with C x R5 | 25 V load voltage |
Key Features
- Supports a maximum load current of 0.15 A for precise low current switching.
- Designed with surface mount mounting type for compact PCB assembly.
- Operates with a maximum load voltage of 25 V and minimum load voltage of 15 V.
- Features SPST contact configuration supporting both AC and DC switching functions.
- Equipped with MOSFET output type ensuring efficient switching with on-state resistance of 7.5 ohms.
- Operates reliably within a temperature range from -40°C to 85°C.
- Compact dimensions of 2.1 mm length, 1.8 mm width, and 2.9 mm height enable space-saving design.
- Low off-state leakage current of 10 nA and low capacitance of 1.5 pF improve signal integrity.
Product Description
Panasonic AQY221N3T PhotoMOS Series Solid State Relay is a high-quality electronic component designed for precise and reliable switching of small loads up to 0.15 A with a load voltage of 25 V. Utilizing surface mount technology, it features a compact VSSOP design that reduces mounting area and lends itself well to high-density circuit boards.
This solid state relay utilizes MOSFET output type and offers AC/DC switching functionality with a single-pole single-throw (SPST) contact configuration. It exhibits an on-state resistance of 7.5 ohms, ensuring low power loss during operation, while maintaining a very low off-state leakage current of 10 nA, which supports high signal fidelity in sensitive electronic circuits.
The device operates efficiently across a wide temperature range from -40°C to 85°C, suitable for industrial, automation, telecommunications, measuring and testing equipment, and telecommunication systems. Its physical dimensions (2.1 mm length by 1.8 mm width by 2.9 mm height) support compact and advanced electronic assemblies.
Notably, this relay complies with RoHS standards, reflecting commitment to environmental safety. It is manufactured in Japan, ensuring high manufacturing quality and consistent performance.
Maximum load current: 0.15 A. Mount type: Surface mount VSSOP packaging. Load voltage range: 15 V minimum to 25 V maximum. Contact configuration: SPST supporting AC/DC switching. On-state resistance: 7.5 ohms. Operating temperature range: -40°C to 85°C.
Low off-state leakage current and capacitance for enhanced signal integrity. RoHS compliant and manufactured in Japan.
This Panasonic PhotoMOS Series Solid State Relay AQY221N3T is ideal for use in industrial electronics, automation control systems, telecommunications infrastructure, and electronic test equipment, where precise, high-speed switching with compact size and reliability is crucial.
Explore the Electronics & Electricals category for more relays and related components available at EnvMart.
