Texas Instruments Operational Amplifier, 9.4 MHz Gain Bandwidth Product, 8-Pin PDIP, 19V TLE2071ACP

Texas Instruments TLE2071ACP Operational Amplifier is a high-performance, JFET-input device from the Excalibur TLE series optimized for industrial and automotive applications. It delivers a gain bandwidth product of 9.4 MHz in a compact 8-pin PDIP package, supporting a supply voltage range from 2.25V up to 19V. This amplifier is engineered to provide low noise, high input impedance, and a fast slew rate of 35 V/µs, making it suitable for precision signal amplification in challenging environments.

The device operates reliably within a temperature range of 0°C to 70°C and meets the automotive standard AEC-Q100, ensuring durability and quality for automotive and industrial electronics. Its output current capacity up to 80 mA allows it to drive diverse loads effectively while maintaining signal fidelity.

Compact in size, its dimensions measuring approximately 10.16 mm in length, 6.6 mm in width, and 4.57 mm in height support easy integration into through-hole PCB designs using the PDIP package type.

Key technical metrics include an input bias current of 5 nA, input offset voltage of 4 mV, and input offset current of 1.4 nA, which contribute to precise and stable amplifier performance for laboratory, manufacturing, automotive, and other industrial applications requiring reliable analog signal processing.

This operational amplifier is RoHS compliant, ensuring environmentally safe manufacturing and usage. It is ideal for use in electronics components, semiconductor circuits, amplifiers and comparators, and systems needing robust signal amplification with strict quality and performance standards.

Features JFET input ensuring low noise and high input impedance. Provides a wide supply voltage range from 2.25V to 19V for flexible operation. Offers a slew rate of 35 V/µs enabling fast response times. Supports output current up to 80 mA suitable for varied applications.

Built to meet automotive standard AEC-Q100 for enhanced reliability. Operates within temperature range of 0°C to 70°C for stable performance. Compact dimensions of 10.16 mm length, 6.6 mm width, and 4.57 mm height. Designed with 1 channel and 8 pins for through-hole mounting in PDIP package.

RoHS compliant ensuring adherence to environmental regulations. Input bias current as low as 5 nA for precision amplification. Input offset voltage of 4 mV and input offset current at 1.4 nA for accuracy.
