Schaffner 3 Phase DIN Rail EMC Filter 20 A 520V AC 60Hz Screw Termination FN3026

Schaffner FN3026 is a high-performance 3 Phase DIN Rail EMC filter designed for eliminating electromagnetic interference in industrial and commercial electrical systems. Rated for a maximum current of 20 amperes and voltage of 520 volts AC at 60 Hz frequency, this filter provides reliable protection for sensitive equipment connected to three-phase power sources.

This filter features a compact and state-of-the-art RFI design housed in a lightweight plastic enclosure. It incorporates a metal ground plate and hinged safety covers with embedded terminals for enhanced safety during installation and maintenance. The termination style uses screws, ensuring secure and stable electrical connections suitable for DIN rail mounting systems commonly found in electrical enclosures.

Designed to operate in ambient temperatures from -25°C to 100°C, the FN3026 provides durable performance across a wide temperature range. Its low leakage current of 400 microamperes reduces unwanted electrical losses, maintaining system efficiency. The product has a power loss of 6.2 watts, highlighting its energy-efficient operation without compromising the protective function.

With physical dimensions of 150 mm length, 78 mm height, and 50 mm depth, this EMC filter fits compactly within electrical control panels and switchboards. Its single-stage filtering design helps reduce electrical noise and improves overall power line quality in industrial, manufacturing, laboratory, and HVAC applications.

Manufactured to high-quality standards in China, the Schaffner FN3026 EMC filter is suitable for use in power line filter applications requiring reliable EMI suppression. It is ideal for installation in DIN rail systems in commercial and industrial settings.

Compact RFI filter in lightweight plastic enclosure. Supports maximum current of 20 A with 520V AC voltage rating. DIN Rail mount type with screw termination style for secure fixing. Designed for 3 phase power systems with 1 filter stage.

Operates reliably between -25°C and 100°C ambient temperature. Low leakage current at 400 μA ensures electrical safety. Power loss rating of 6.2 W for efficient energy use. Rigid construction includes metal ground plate and hinged safety covers.

Dimensions: 150 mm length, 78 mm height, 50 mm depth for compact installation. Manufactured in China, complies with relevant industry standards. Explore EnvMart for a wide range of Schaffner EMC filters and other electronic components to meet your industrial and commercial needs with guaranteed quality and performance.
