Schaffner 1.5 mH Common Mode Choke 36 A IDC 3.65 mΩ RDC 600 V AC Lead Wire Mount RD8137-36-1M5

Schaffner RD8137-36-1M5 is a high-performance 1.5 mH Common Mode Choke engineered for efficient attenuation of common-mode and asymmetric interference signals in electronic circuits. Rated for a maximum DC current of 36 A and a maximum DC resistance of 3.65 mΩ, this component is ideal for power line input filtering where noise reduction is critical.

Its construction with lead wire mounting and wire termination style facilitates easy and secure PCB integration in bulk packaging format. The choke measures 80 mm in diameter, 50 mm in height, and 50 mm in depth with a lead length of 250 mm, providing convenient installation within various industrial and electronic equipment.

Designed to operate reliably within a temperature range of -25°C to 110°C and with an inductance tolerance of -30% to +50%, it suits demanding applications in EMI filter networks, decoupling tasks, and low power switch mode regulators. The maximum self-resonant frequency of 400 Hz ensures effective noise attenuation at relevant frequencies. Operating voltage withstand up to 600 V AC adds further robustness for commercial and industrial environments.

Schaffner's RD series including this model meets UL and RoHS approvals, reflecting a high standard in safety and environmental responsibility. The lead diameter of 1.5 mm contributes to mechanical durability and electrical reliability.

This product supports a wide range of industrial applications including electronic equipment filtration, power line noise suppression, and EMI protection. Its stable characteristics and certified manufacturing quality make it a trusted component choice for engineers in the electronics manufacturing, power distribution, and control systems sectors.

This choke features a maximum self-resonant frequency of 400 Hz ensuring stable operation in common mode noise attenuation. Capable of withstanding maximum voltage up to 600 V AC suitable for typical industrial environments.

Lead wire mounting and wire termination style allow for easy integration in bulk packaging form. Constructed with a compact dimension of 80 mm diameter, 50 mm height, and 50 mm depth allowing for versatile PCB layout. Operates reliably within a temperature range from -25°C minimum to 110°C maximum for industrial conditions.

Inductance tolerance ranges from -30% to +50%, providing performance flexibility to handle various filtering needs. Lead diameter is 1.5 mm, optimized for stable electrical connection and mechanical strength. Meets UL and RoHS standards ensuring compliance with industry safety and environmental regulations.
