Crydom CX Series Solid State Relay PCB Mount 5A Load 660Vrms Load 15-32V DC Control CXE480D5

Crydom CXE480D5 solid state relay from the CX Series is a reliable electronic switching device designed for PCB mounting applications. It supports a maximum load current of 5 Amperes and can switch AC voltages up to 660 Vrms, making it suitable for controlling a wide range of industrial and automation loads.

This relay features a single-pole single-throw (SPST) contact configuration with instantaneous switching function, ensuring fast and efficient switching operations. It utilizes SCR output type components that guarantee durable and low-loss performance.

With operating temperature range from -30°C to +80°C, the relay is built to perform reliably in demanding industrial environments. It provides an off-state leakage current as low as 0.1 mArms, thereby minimizing power losses during operation.

The CXE480D5 model incorporates an input control voltage ranging from 15V DC to 32V DC with an input-output capacitance of 10pF, which helps reduce electrical noise and interference. Its compact SIP-4 package with through-hole terminals allows for straightforward PCB mounting and integration into control equipment.

Additional product highlights include an exceptional surge rating with a peak 1-cycle surge current capability of 250A, providing robustness against transient conditions. The relay complies with international safety and quality standards, including UL, CSA, VDE, CE, and RoHS certifications.

Supports a maximum load current of 5 Amperes for consistent switching performance. Designed for PCB mounting with a through-hole terminal type for easy installation. Switches loads up to 660 Vrms, suitable for industrial AC control applications.

Operates within temperature range from -30°C to +80°C ensuring durability in various environments. Utilizes SCR output type with instantaneous switching function for reliable operation. Features a compact SIP-4 package with dimensions 43.1mm length, 7.6mm width, and 25.4mm height.

Low off-state leakage current of 0.1 mArms minimizes power loss and heat generation. Exceptional surge rating with 250A peak 1-cycle surge capability provides system protection. Input control voltage range from 15V to 32V DC offers flexible control options.

Input-Output capacitance of 10pF reduces noise and interference in circuits. Complies with UL, CSA, VDE, CE, and RoHS standards ensuring safety and environmental compliance.

This solid state relay is ideal for applications in industrial automation systems, manufacturing equipment, HVAC systems, and various control circuits where reliable and efficient switching is necessary. Its robust design and compliance with multiple safety standards make it suitable for commercial and industrial use.
