Wurth Elektronik Chassis Mount EMC Filter 14A 250V 100Hz Operating Frequency WE-CLFS 810913014112
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 54mm |
| Length | 43mm |
| Depth | 29mm |
| Mount Type | Chassis Mount |
| Operating Frequency | 100, -25Hz |
| Series | WE-CLFS |
| Maximum Operating Temperature | 100°C |
| Resistance | 300mΩ |
| Capacitance | 1μF |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 14A |
| Number of Phases | 1 |
| Leakage Current | 0mA |
| Maximum Voltage | 250V |
| Inductance | 2.2mH |
| Standards/Approvals | EN 50110-1 |
| Termination Style | Screw |
Key Features
- Provides broadband noise suppression in both common and differential modes.
- Features a 2.2mH inductance and 1μF X2-class capacitance for effective filtering.
- Operates reliably between temperatures -25°C and 100°C.
- Designed for quick chassis mounting with screw termination style and crimp cable lug connection.
- Complies with UL 94 V-0 flammability standard and EN 50110-1 approvals.
- Ideal for industrial electronics, telecommunications, switched-mode power supplies, household goods, and DC applications.
Product Description
Wurth Elektronik 810913014112 is a high-quality chassis mount EMC filter designed for single-phase power line filtering applications operating at 100Hz and -25Hz frequencies. Rated for 14 amperes and a maximum voltage of 250 volts, it provides efficient broadband noise suppression in both common and differential modes. The filter incorporates 2.2mH inductance and a 1μF X2-class capacitance, ensuring reliable and stable filtering performance across various electrical environments.
Manufactured to operate within a temperature range of -25°C to 100°C, this filter is suited for demanding industrial electronics, telecommunications systems, switched-mode power supplies, household electrical appliances, and DC-powered equipment. The product features a screw termination style for firm connections and is designed to be quickly installed on chassis via screw mounting. The crimp cable lug facilitates straightforward electrical connectivity.
The filter meets stringent safety and flammability standards, including UL 94 V-0 and EN 50110-1. With resistance of 300 milliohms and zero leakage current, it guarantees minimal power loss and high efficiency. Its compact dimensions (43mm length, 54mm height, and 29mm depth) optimize space usage in electrical assemblies.
This Wurth Elektronik EMC filter, model 810913014112, originates from China, where it is produced under strict quality control to ensure long service life and dependable performance. The product supports advanced noise filtering needs for industrial, commercial, and residential electronics.
Provides broadband noise suppression in both common and differential modes. Features a 2.2mH inductance and 1μF X2-class capacitance for effective filtering. Operates reliably between temperatures -25°C and 100°C. Designed for quick chassis mounting with screw termination style and crimp cable lug connection.
Complies with UL 94 V-0 flammability standard and EN 50110-1 approvals. Ideal for industrial electronics, telecommunications, switched-mode power supplies, household goods, and DC applications. Explore the extensive range of EMC filters available on EnvMart for optimized noise management in your electronic designs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this EMC filter is 14 amperes.
This model operates at a maximum voltage of 250 volts.
It features an inductance value of 2.2mH.
The dimensions of the filter are 43mm in length, 54mm in height, and 29mm in depth.
It operates reliably between -25°C and 100°C.
This model uses a screw termination style for installation.
It complies with the UL 94 V-0 flammability standard and EN 50110-1 approvals.
The capacitance rating of this EMC filter is 1μF, classified as X2-class.
This filter has a leakage current of 0mA, ensuring minimal power loss.
It is suitable for industrial electronics, telecommunications, switched-mode power supplies, household goods, and DC applications.
The resistance of this filter is 300 milliohms.
This EMC filter originates from China, where it is produced under strict quality control.
