Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 680nH ±20% 19.5A Idc ETQP4M

Panasonic ETQP4M Shielded Wirewound Surface Mount Inductor with a metal composite core provides reliable performance in demanding electronic applications. This inductor has an inductance of 680nH with a tolerance of ±20%, capable of handling a maximum DC current of 19.5A, making it suitable for high current filtering and noise suppression needs in industrial, automotive, and consumer electronics.

The wirewound construction on a metal composite core ensures excellent inductance stability across a wide temperature range and reduces audible noise. The robust shielded design minimizes electromagnetic interference, improving circuit performance and reliability.

Designed to operate in harsh environments, the ETQP4M withstands temperatures from -55°C up to 155°C, meeting AEC-Q200 automotive standards for quality and reliability. The surface mount package, supplied in tape and reel format, facilitates efficient automated PCB assembly.

This inductor’s physical size with 8.5mm length, 4mm height, and 8mm depth allows compact PCB layouts. Its low DC resistance of 3.21 milliohm enhances energy efficiency within circuits.

Incorporates a metal composite core for high heat resistance and durability. Wirewound construction for excellent inductance stability and low audible noise. Features shielded design to reduce electromagnetic interference.

Operates reliably up to 155°C with high vibration resistance. Complies with automotive standard AEC-Q200 for stringent quality assurance. Surface mount package with tape & reel packaging for automated assembly. Minimum operating temperature of -55°C ensures broad environmental suitability.

Maximum DC resistance of 3.21 milliohm supports efficient current flow. Compact dimensions: length 8.5mm, height 4mm, depth 8mm for flexible PCB integration.

This component is ideal for use in industrial electronics, automotive systems, power supplies, and other applications requiring stability under temperature extremes and high current operation.

Explore extensive Panasonic electronic components for advanced design solutions and reliability at EnvMart.
