Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 3.3 μH ±20 % 12.6 A Idc ETQP4M

Panasonic ETQP4M shielded wirewound surface mount inductor with a metal composite core features an inductance of 3.3 μH with a tolerance of ±20 %, supporting a maximum DC current of 12.6 A. This inductor is designed for high heat resistance operation up to 155°C, making it suitable for demanding electronic applications including automotive and industrial uses.

The shielded construction offers superior electromagnetic noise suppression, crucial for sensitive circuits operating at high frequencies. The metal composite core enhances inductance stability by mitigating magnetic flux distortions, while the wirewound construction delivers low DC resistance of 10.34 mΩ, improving energy efficiency.

Packaged in tape and reel format, the product supports high-volume automated PCB assembly processes. Compliance with the automotive standard AEC-Q200 guarantees the inductor's reliability in automotive electronic systems.

Operating temperature range from -55°C to 155°C and the robust design ensure durability under harsh conditions. The component's compact dimensions (length 10.7 mm, height 4 mm, depth 10 mm) and surface mount termination style facilitate integration into modern compact circuit boards.

High heat resistant wirewound inductor with metal composite core. Shielded design minimizes noise for critical circuits. Automotive AEC-Q200 standard compliant for enhanced reliability. Tape and reel packaging enables efficient manufacturing.

Compact surface mount case dimensions for space-saving PCB layout.

This Panasonic ETQP4M series inductor is ideal for use in power supplies, automotive electronics, industrial control circuits, and noise filtering applications requiring stable inductance and high current handling capabilities.
