| Country of Origin | Taiwan |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 55°C to +125°C |
| Height | 0.5mm |
| Length | 1mm |
| Depth | 0.5mm |
| Packaging | Tape & Reel |
| Series | WE-MK |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ceramic |
| Inductance | 6.8nH |
| Standards/Approvals | REACH, IEC 61249-2-21, JEDEC JS709B, RoHS |
| Maximum DC Current | 300mA |
| Maximum DC Resistance | 290mΩ |
| Inductance Tolerance | 5 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 4.2GHz |
| Minimum Quality Factor | 8 |
| Inductor Construction | Multilayer |
| Automotive Standard | AEC-Q200 |
Wurth Elektronik 7447840068 WE-MK is a high-performance unshielded multilayer Surface Mount Inductor featuring a ceramic core. Designed for use in high frequency circuits such as Bluetooth and wireless LAN, this inductor delivers precise inductance of 6.8 nH with a tolerance of 5%, ensuring circuit reliability.
The multilayer ceramic structure integrates the coil in a compact form factor with dimensions of 1 mm length, 0.5 mm height, and 0.5 mm depth, making it suitable for densely packed PCB layouts. It supports a maximum DC current of 300 mA and maintains inductance stability over a wide temperature range from -55°C to +125°C.
This WE-MK series inductor features a minimum quality factor of 8 and a maximum DC resistance of 290 milliohms, supporting efficient circuit performance with minimal losses. Its high self-resonant frequency of 4.2 GHz makes it ideal for RF and microwave applications.
The inductor is compliant with automotive standard AEC-Q200 and environmental regulations such as RoHS, REACH, IEC 61249-2-21, and JEDEC JS709B, ensuring suitability for automotive and industrial electronics.
Packaging is provided as tape and reel, facilitating automated surface mount assembly processes. The ceramic core material enhances thermal stability and durability under demanding operating conditions.
Inductance stable over temperature from -55°C to +125°C. Multilayer ceramic structure with integrated coil for compactness and performance. High self-resonant frequency of 4.2 GHz supports high-frequency circuit design. Automotive standard AEC-Q200 qualification ensures reliability in automotive applications.
Packaging as tape and reel supports efficient manufacturing and component handling. Ceramic core material provides excellent thermal and mechanical stability. Recommended for Bluetooth, wireless LAN, and other RF applications.
Surface mount termination style for modern PCB assembly.
This product is an essential component for industrial, automotive, and consumer electronics manufacturing. Explore more Wurth Elektronik inductors and components in EnvMart's Electronics & Electricals catalog for advanced circuit solutions.
