Wurth Elektronik WE-MK Unshielded Multilayer Surface Mount Inductor with Ceramic Core 5.1 nH 5% 270 mA 7447820051

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-MK Unshielded Multilayer Surface Mount Inductor with Ceramic Core 5.1 nH 5% 270 mA 7447820051

Name: Wurth Elektronik WE-MK Unshielded Multilayer Surface Mount Inductor with Ceramic Core 5.1 nH 5% 270 mA 7447820051
Brand: Wurth Elektronik
SKU: 403427
Price: 0.05 USD
Availability: InStock



Category Surface Mount Inductor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Brand	Wurth Elektronik
Operating Temperature	- 55°C to +125°C
Height	0.3mm
Length	0.6mm
Depth	0.3mm
Packaging	Tape & Reel
Series	WE-MK
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Core Material	Ceramic
Inductance	5.1nH
Standards/Approvals	RoHS, REACH, JEDEC JS709B, IEC 61249-2-21
Maximum DC Current	270mA
Maximum DC Resistance	330mΩ
Inductance Tolerance	5 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	5GHz
Minimum Quality Factor	4
Inductor Construction	Multilayer
Automotive Standard	AEC-Q200

Key Features

Unshielded multilayer design suitable for high frequency applications.
Ceramic core ensures stable inductance over temperature range.
Compact size with length 0.6 mm, height 0.3 mm, and depth 0.3 mm.
Compliance with automotive standard AEC-Q200.
RoHS, REACH, JEDEC JS709B, IEC 61249-2-21 certified materials.
Maximum DC resistance of 330 mΩ for efficient performance.
Operating temperature range from -55°C to 125°C.
Termination style is surface mount with tape & reel packaging.

Product Description

Wurth Elektronik 7447820051 is an unshielded multilayer surface mount inductor featuring a ceramic core and an inductance value of 5.1 nH with a tolerance of 5%. This component is designed for use in high-frequency electronics, including Bluetooth and wireless LAN circuits, ensuring stable inductance characteristics across temperature variations.

The inductor's compact construction measures 0.6 mm in length, 0.3 mm in height, and 0.3 mm in depth, making it ideal for densely packed circuit boards. It withstands a maximum DC current of 270 mA and maintains a low DC resistance of 330 mΩ, promoting efficient energy handling.

This product complies with the automotive standard AEC-Q200 and environmental standards such as RoHS and REACH, alongside certifications including JEDEC JS709B and IEC 61249-2-21. The termination style is surface mount, packaged in tape and reel format for automated assembly processes.

Engineered for reliable operation in demanding environments, the inductor supports an operating temperature range from -55°C up to 125°C. Its high self-resonant frequency of 5 GHz and a minimum quality factor of 4 ensure it performs effectively in high-frequency signal applications.

Unshielded multilayer construction suitable for high-frequency circuit designs. Ceramic core offers excellent thermal stability of inductance. Compact dimensions enable integration in space-constrained PCBs. Compliance with automotive and international environmental standards.

Low DC resistance enhances current handling efficiency. Wide operating temperature range for versatile applications. Surface mount termination optimized for automated production lines. High self-resonant frequency supports demanding signal frequencies.

Minimum quality factor ensures optimal inductive performance.

This Wurth Elektronik inductor is commonly used in industrial, automotive, telecommunications, and consumer electronics manufacturing sectors where miniature and reliable inductive components are required. Its robustness and compliance make it ideal for prototypes and large-scale production projects. Browse EnvMart for more Surface Mount Inductors and electronic components by leading brands.
