Wurth Elektronik 3485 Series Pluggable Terminal Block, 7-Contact, 5.08 mm Pitch, 1 Row, 1.6kV Voltage, 20A 691348500007
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 1.6kV |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 20A |
| Length | 37.06mm |
| Depth | 15mm |
| Width | 19.2mm |
| Housing Material | Polyamide |
| Series | 3485 |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 7 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.32mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 22AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Solder |
Key Features
- The terminal block supports a current rating of 20A for reliable power delivery.
- The housing is made of durable polyamide material ensuring electrical insulation and longevity.
- Compatible with wire sizes ranging from 22 AWG to 12 AWG for versatile wiring options.
- Vertical orientation with solder wire connection method simplifies PCB mounting.
- The connector gender is male with a voltage rating of 1.6kV for high voltage applications.
- The compact dimensions of 37.06 mm length, 19.2 mm width, and 15 mm depth enable space-saving installations.
- Colour coded green for easy identification and conformity to RoHS standards ensures environmental compliance.
Product Description
Wurth Elektronik 691348500007 is a high-quality 3485 Series Pluggable Terminal Block designed for industrial power and signal applications.
This component features 7 contact points configured in a single row with a 5.08 millimeter pitch, offering a secure and reliable connection interface suitable for various PCB layouts.
The terminal block has a current capacity of 20A and supports wire sizes from 0.32 mm² to 3.31 mm² (22 to 12 AWG), meeting wide-ranging wiring requirements in electrical assemblies.
Its polyamide housing material provides excellent insulation and durability, making it suitable for demanding industrial environments. The vertical orientation with a solder-type wire connection method simplifies assembly and enhances mechanical stability.
Rated for voltage up to 1.6 kV, it ensures safe operation in high-voltage circuits. The green color housing aids in identification and system integration while complying with RoHS environmental standards.
Typical applications include connector interfaces in industrial automation, power control, electronic circuit boards, and other commercial and manufacturing equipment requiring dependable electrical connections.
The terminal block supports a maximum current of 20 amperes. Wire size compatibility ranges from 22 AWG to 12 AWG. Dimensions are precisely 37.06 mm length, 19.2 mm width, and 15 mm depth for compact integration. Voltage rating of 1.6 kilovolts suitable for high voltage industrial systems.
Housing made from high-strength polyamide to ensure electrical and mechanical reliability. Explore the extensive range of Wurth Elektronik terminal blocks and connectors at EnvMart for your electronics component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block supports a current rating of 20A, making it suitable for reliable power delivery in various applications.
It has a voltage rating of 1.6kV, which is suitable for high voltage applications.
This terminal block is compatible with wire sizes ranging from 22 AWG to 12 AWG, accommodating a variety of wiring needs.
The dimensions of this terminal block are 37.06 mm in length, 19.2 mm in width, and 15 mm in depth, allowing for compact installations.
The housing is made of polyamide, which provides excellent electrical insulation and durability.
This model features 7 contact points configured in a single row, providing a reliable connection interface.
The terminal block is designed for vertical orientation, which simplifies PCB mounting and enhances mechanical stability.
The pitch size of the contacts is 5.08 mm, which is standard for many industrial applications.
It uses a solder-type wire connection method, which is common for secure electrical connections.
Yes, it complies with RoHS standards, ensuring environmental compliance in its use.
The connector gender is male, which is typical for many terminal block applications.
The country of origin for this terminal block is China.
