Samtec High Reliability PCB Socket 40-Contact, 2 Row, 1.27 mm Pitch, 3.2A Current, 250V Through Hole Solder SFM-120-01-L-D-A

Samtec SFM-120-01-L-D-A is a high reliability PCB socket engineered for precise and durable electrical connections on printed circuit boards. This 40-contact socket features a 2-row configuration with a 1.27 mm pitch, optimized for through-hole solder mounting to ensure reliable mechanical and electrical performance.

The connector system supports both board-to-board and cable interfacing, making it versatile for complex electronic assemblies. The contact system utilizes Tiger Eye™ technology, providing consistent and low-resistance connections over extended use.

Constructed with a liquid crystal polymer housing, this socket offers excellent mechanical strength and thermal stability across a wide operating temperature range of -55°C to 125°C. The contacts are crafted from beryllium copper alloy and plated with gold to resist corrosion and enhance conductivity.

Electrical specifications include a maximum current capacity of 3.2A and an operating voltage rating of 250V, accommodating demanding power requirements in industrial, laboratory, and manufacturing applications.

The product's 12 mm stacking height allows for compact PCB design and ergonomics. Installation is flexible with solder through-hole and surface mount terminations. Additionally, screw down and solder nail options are available to meet ruggedness demands, making the socket suitable for harsh environments and extended life cycles.

The contact system uses Tiger Eye™ technology for robust signal integrity. Supports 3.2A current and operates at voltages up to 250V safely. Constructed with a liquid crystal polymer housing for durability. Gold-plated beryllium copper alloy contacts ensure reliable connections.

Suitable for board-to-board and cable connector systems. Operating temperature range from -55°C to 125°C allows for versatile environmental conditions. Stacking height of 12 mm supports compact and efficient PCB layouts.

Termination options include solder through-hole and surface mount for installation flexibility. Special features include screw down and solder nail options for rugged use cases. Designed to meet high reliability requirements with no specific compliance certifications.

This Samtec PCB socket is ideal for use in electronics manufacturing, industrial control systems, communication devices, and laboratory instrumentation, where secure and reliable connections are critical.
