Samtec MMS Series Straight Through Hole PCB Socket 4-Contact 2 Row 2 mm Pitch Solder MMS-102-01-L-DV

Samtec MMS-102-01-L-DV is a high-quality straight through hole PCB socket designed for robust board-to-board connectivity applications. Featuring a 4-contact, 2-row configuration with a precise 2 mm pitch, this connector demonstrates reliable performance in electronic assemblies.

The socket employs the Tiger Claw™ contact system, which ensures consistent mechanical and electrical contact. The contacts are crafted from bronze with gold plating, enhancing conductivity and protecting against corrosion over time. Its housing is constructed from Liquid Crystal Polymer, a material selected for its durability and ability to withstand demanding operating temperatures ranging from -55°C to 125°C.

This connector is terminated through a solder mount process offering both vertical and horizontal orientations, providing design flexibility for various PCB configurations. It supports current ratings up to 3.9 A, making it suitable for medium power circuits.

Designed for industrial electronics, manufacturing, and electronic development applications, this PCB socket supports single and double row arrays up to 80 pins, suitable for compact and dense PCB layouts.

The pitch is precisely 2.00 mm ensuring reliable spacing and fit. Contacts utilize Tiger Claw™ system for strong and consistent connectivity. Supports a current rating of 3.9 A for moderate power applications. Constructed with bronze contact material and gold plating for excellent conductivity and corrosion resistance.

Housing is made of Liquid Crystal Polymer, providing high durability and temperature resistance. Designed for through-hole solder termination with vertical and horizontal orientation options. Operates reliably within the temperature range of -55°C to +125°C.

Suitable for single and double row configurations up to 80 pins, ideal for versatile PCB layouts.

This connector is an essential component for electronics manufacturing, prototyping, and repair, offering reliable electrical connections in demanding environments. Its compatibility with standard industry pitch and robust materials ensures long-term performance in industrial, laboratory, and commercial electronics applications.
