TDK Panel Mount EMC Filter 65 A 520V AC 50Hz/60Hz Screw Termination 3 Phase B84143A0065R107
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 80mm |
| Length | 188mm |
| Model | B84143A0065R107 |
| Depth | 84.5mm |
| Mount Type | Panel Mount |
| Operating Frequency | 50, 60Hz |
| Series | B84143A*R107 |
| Maximum Operating Temperature | 100°C |
| Resistance | 940Ω |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 65A |
| Number of Phases | 3 |
| Leakage Current | 3.4mA |
| Maximum Voltage | 520V ac |
| Standards/Approvals | UL1283 |
| Termination Style | Screw |
Key Features
- Panel mount design with screw termination ensures secure installation.
- Operating frequency supports both 50 Hz and 60 Hz power systems.
- Compact dimensions of 188 mm length, 80 mm height, and 84.5 mm depth.
- Wide operating temperature range from -25°C to 100°C for durable performance.
- Low leakage current of 3.4 mA to enhance safety and efficiency.
- High resistance rating of 940 Ω for reliable electromagnetic compatibility.
- Complies with UL1283 standards for electrical safety and EMI filtering.
- Manufactured in Hungary with a cost-optimized and compact design for easy installation.
Product Description
TDK B84143A0065R107 is a high-quality Panel Mount EMC Filter engineered for 3-phase power systems with a maximum current rating of 65 A and voltage rating of 520 V AC at 50 Hz and 60 Hz frequencies. This filter utilizes screw termination to ensure a secure and reliable connection suitable for industrial and commercial electrical panels.
The filter offers a compact form factor with dimensions measuring 188 mm in length, 80 mm in height, and 84.5 mm in depth. It is designed to perform effectively in temperature environments ranging from -25°C up to 100°C, facilitating robust operation in diverse conditions.
Featuring a low leakage current of 3.4 mA and a resistance value of 940 Ω, this device is optimized for efficient electromagnetic interference (EMI) suppression, thereby enhancing the reliability and safety of electrical installations.
Certified under the UL1283 standard, the filter meets high industry safety and quality benchmarks, ensuring compliance with international norms. The design emphasizes ease of installation with a compact and cost-efficient construction, making it practical for various industrial equipment, automation, HVAC systems, and power distribution applications.
The front side provides a degree of protection rated at IP 40 when fitted with the power plug, signaling protection from solid objects larger than 1 mm while not protected against water ingress.
This EMC filter is suitable for reducing conducted interference in power lines of three-phase electrical installations commonly used in manufacturing, control panels, and power supply systems.
Panel mount design with screw termination ensures secure installation. Operating frequency supports both 50 Hz and 60 Hz power systems. Compact dimensions of 188 mm length, 80 mm height, and 84.5 mm depth. Wide operating temperature range from -25°C to 100°C for durable performance.
Low leakage current of 3.4 mA to enhance safety and efficiency. High resistance rating of 940 Ω for reliable electromagnetic compatibility. Complies with UL1283 standards for electrical safety and EMI filtering. Manufactured in Hungary with a cost-optimized and compact design for easy installation.
Explore more EMC filters and power line filters on EnvMart to find compatible components for your industrial and commercial projects.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this EMC filter is 65 A.
This model has a maximum voltage rating of 520 V AC.
It supports both 50 Hz and 60 Hz power systems.
The dimensions are 188 mm in length, 80 mm in height, and 84.5 mm in depth.
The leakage current is 3.4 mA.
It has a resistance rating of 940 Ω.
The operating temperature range is from -25°C to 100°C.
This model uses screw termination for secure installation.
It complies with UL1283 standards for electrical safety and EMI filtering.
It is manufactured in Hungary.
The front side provides a protection rating of IP 40.
It is suitable for reducing conducted interference in three-phase electrical installations, commonly used in manufacturing and power supply systems.
