| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1mm |
| Length | 2.2mm |
| Model | BAS40-05W,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | BAS40-05W |
| Maximum Operating Temperature | 150°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 120mA |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200mA |
| Maximum Forward Voltage Vf | 1V |
Nexperia BAS40-05W,115 is a 40 V, 120 mA Schottky diode packaged in a compact 3-pin SC-70 surface-mount device configuration. Its low forward voltage drop and low leakage current attributes enable high efficiency in rectification and switching applications.
This diode features a common cathode configuration and a peak reverse repetitive voltage of 40 V. It is capable of handling a maximum continuous forward current of 120 mA and peak forward surge current of 200 mA, ensuring reliable high-performance operation.
The operating temperature range for this device extends from -65°C to 150°C, making it suitable for harsh environmental conditions typically encountered in industrial electronics, communication systems, and power supply circuits.
Physically, it measures 2.2 mm in length, 1.35 mm in width, and 1 mm in height, supporting low-profile, space-constrained PCB designs. The SC-70 package type facilitates easy surface mounting and effective thermal dissipation.
Key electrical characteristics include a maximum forward voltage of 1 V and a low peak reverse current of 10 microamps, which contribute to minimal power loss and enhanced device longevity.
Applications for the Nexperia BAS40-05W,115 Schottky Diode include high-frequency rectification, voltage clamping, and efficient power conversion in consumer electronics, automotive electronics, and telecommunications equipment.
This diode has a common cathode configuration with a Schottky rectifier type. It is optimized for low forward voltage drop and high junction temperature tolerance. The package type is SC-70 with 3 pins for mounting on a PCB.
It supports a peak reverse current of 10 microamps and peak non-repetitive forward surge current of 200 mA. The device operates within a temperature range of -65°C to 150°C. It has physical dimensions of length 2.2 mm, width 1.35 mm, and height 1 mm.
Low leakage current and negligible power switching losses make it ideal for efficient rectification. This diode is suitable for use in industrial electronic, communication, and power management applications. The product is new and compliant with RoHS standards.
