Nexperia Schottky Diode 70 V 70 mA 4-Pin SOT-143 Surface Mount Diode BAS70-07,215

Nexperia BAS70-07,215 Schottky Diode is a high-efficiency, ultra-small semiconductor diode designed for surface mount technology using a 4-pin SOT-143 package. It delivers a maximum continuous forward current of 70 mA and peak reverse voltage of 70 V, making it ideal for low forward voltage drop applications and circuits requiring fast switching speed.

This Schottky diode is optimized to reduce power losses with a maximum forward voltage of 1 V and offers excellent temperature stability, functioning reliably across a temperature range from -65°C to 150°C. Its small physical dimensions of 3 mm length, 1.4 mm width, and 1 mm height facilitate integration into compact circuit layouts and portable electronic devices.

The diode configuration is isolated to offer design flexibility, along with a peak reverse current of only 10μA minimizing leakage currents. It also has a peak non-repetitive forward surge current rating of 100 mA to withstand transient surges. The device complies with automotive standard AEC-Q101, making it suitable for automotive and industrial electronics applications where reliability is critical.

Applications for the Nexperia BAS70-07,215 include power rectification, voltage clamping, and switching circuits in telecommunications, computing, automotive electronics, and consumer devices. Its low capacitance and low power switching losses improve overall circuit efficiency and response times for fast and switching frequency operations.

This diode offers a maximum continuous forward current of 70 mA. Designed with low forward voltage drop of up to 1 V for efficient power management. Features a peak reverse repetitive voltage of 70 V for reliable blocking capabilities.

Operates reliably between -65°C and 150°C, fulfilling demanding thermal requirements. The compact dimensions are 3 mm length, 1.4 mm width, and 1 mm height, optimized for low-profile designs. Incorporates low capacitance and negligible power switching losses for enhanced performance in switching applications.

Meets automotive standard AEC-Q101 ensuring suitability for automotive electronics. Isolated diode configuration providing flexibility in circuit design. Peak non-repetitive forward surge current is 100 mA for transient handling.

Manufactured in China with new product condition guaranteed. Explore EnvMart’s extensive range of Schottky Diodes and semiconductor components for your industrial, automotive, and electronic manufacturing needs.
