TDK EMC Filter 180 A 480V AC 50Hz/60Hz Flange Mount Screw Termination 3-Phase B84143A0180R000
Specifications
| Country of Origin | China |
|---|---|
| Brand | TDK |
| Height | 141mm |
| Length | 404mm |
| Model | B84143A0180R000 |
| Depth | 171mm |
| Mount Type | Flange |
| Operating Frequency | 50, 60Hz |
| Series | B84143A*R000 |
| Maximum Operating Temperature | 100°C |
| Resistance | 400Ω |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 180A |
| Number of Phases | 3 |
| Leakage Current | 2.73mA |
| Maximum Voltage | 480V ac |
| Standards/Approvals | CSA 22.2 No. 8, UL 1283 |
| Termination Style | Screw |
Key Features
- High insertion loss provides excellent EMC compliance.
- Flange mount with screw termination enhances secure installation.
- Optimized for long motor cables under full load conditions.
- Low leakage current of 2.73 mA ensures energy efficiency.
- Operates effectively between -25°C and 100°C.
- Resistant to 400Ω for reliable performance.
- Meets UL 1283 and CSA 22.2 No. 8 safety standards.
- Suitable for frequency converters in motor drives including lifts, pumps, and conveyor systems.
Product Description
TDK B84143A0180R000 EMC Filter offers robust electromagnetic interference mitigation for industrial equipment requiring 180 A maximum current and 480V AC maximum voltage. This 3-phase filter supports operating frequencies of 50Hz and 60Hz, making it adaptable for various power systems worldwide.
Constructed with a flange mounting type and screw termination style, this filter ensures reliable and secure installation in demanding industrial environments. It features a low leakage current of 2.73 mA and resistance of 400Ω, contributing to energy-efficient operation.
The filter is optimized for extended motor cables under full load, making it ideal for use in frequency converters for motor drives such as lifts, pumps, traction and conveyor systems, air conditioning units, wind-driven power plants, and power supplies.
Designed to operate reliably in temperature ranges from -25°C to 100°C, it complies with UL 1283 and CSA 22.2 No. 8 1996 standards, ensuring safety and performance.
Physical dimensions include a length of 404 mm, height of 141 mm, and depth of 171 mm, fitting well in typical industrial setups. This product is manufactured in China and belongs to the B84143-Ax-R series known for very high insertion loss and low leakage current.
High insertion loss for EMC compliance. Flange mounting for secure fitting. Low leakage current enhancing safety and efficiency. Optimized for long motor cable connections under load. Robust construction with screw termination.
Meets international safety standards UL 1283 and CSA 22.2 No. 8. Broad application range including motor drives and power supplies. Suitable for industrial, HVAC, manufacturing, and power generation environments. Dimensions: 404mm x 171mm x 141mm.
Explore further EMC filters and power line filters at EnvMart for comprehensive industrial and electronic component needs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this EMC filter is 180 A.
This model operates at a maximum voltage of 480 V AC.
The dimensions of this unit are 404 mm in length, 171 mm in depth, and 141 mm in height.
The leakage current of this EMC filter is 2.73 mA.
It can operate effectively in temperatures ranging from -25°C to 100°C.
This EMC filter features a flange mounting style with screw termination for secure installation.
It meets the safety standards of UL 1283 and CSA 22.2 No. 8.
The resistance of this model is 400Ω.
It supports operating frequencies of 50 Hz and 60 Hz.
This model belongs to the B84143-Ax-R series.
The high insertion loss provides excellent EMC compliance, mitigating electromagnetic interference.
