Vishay 6767 Shielded Surface Mount Inductor with Metal Composite Core 22 μH ±20% 12 A Maximum DC Current IHLP6767GZER220M11

Vishay IHLP6767GZER220M11 is a high-current, low-profile shielded surface mount inductor with a metal composite core designed for advanced electronic applications. This inductor has an inductance of 22 μH with a tolerance of ±20%, allowing reliable performance in precision circuits. It supports a maximum DC current of 12 A, enabling handling of high transient current spikes without saturation, making it ideal for power-sensitive devices.

The IHLP6767GZ-11 series inductors feature a magnetically shielded wire wound construction that significantly lowers buzz noise and electromagnetic interference, enhancing signal integrity in compact electronics. The device is moulded with a metal composite core, ensuring robust mechanical properties and thermal stability across its operating temperature range of -55°C to 125°C.

Its compact dimensions (Length: 17.15 mm, Height: 7 mm, Depth: 17.15 mm) and surface mount termination style facilitate easy PCB integration for applications such as PDAs, notebooks, desktops, servers, and high current POL converters. Additional applications include low-profile, high-current power supplies, battery-powered devices, and DC/DC converters in distributed power systems, including FPGA power management.

This series complies with RoHS and is halogen-free according to IEC 61249-2-21, supporting environmentally conscious design requirements. With a maximum self-resonant frequency of 4.3 MHz and a low DC resistance of 21 mΩ, it ensures efficient operation at high frequencies with minimal power loss.

Magnetically shielded inductor construction for EMI reduction. High current handling capability at 12 A maximum DC current. Metal composite core for improved electrical and thermal performance. Wide operating temperature range from -55°C to 125°C.

Surface mount package type (6767) suitable for automated PCB assembly. Low DC resistance of 21 mΩ reduces power dissipation. Halogen-free and RoHS compliant for environmental safety. Maximum self-resonant frequency of 4.3 MHz for high-frequency use cases.

Compact dimensions enable integration in space-constrained designs.

This Vishay IHLP6767GZER220M11 inductor is suited for industrial, computing, telecommunications, and power supply applications that demand reliable, high-current inductors maintaining low noise and high efficiency. Browse more Surface Mount Inductors and Vishay branded components on EnvMart for your electronics assembly needs.
