Vishay Shielded Surface Mount Inductor IHLP2020CZER4R7M01 4.7 μH ±20% 3.5 A DC Current 2020 Package

Vishay IHLP2020CZER4R7M01 shielded surface mount inductor delivers 4.7 μH inductance with a tolerance of ±20%, supporting a maximum DC current of 3.5 A in a compact 2020 package (5.49mm × 5.18mm × 3mm). Featuring a metal composite core, this inductor offers magnetically shielded wire wound construction that effectively minimizes electrical noise and electromagnetic interference. It has a low DC resistance of 77.5 mΩ which ensures efficient power handling with minimal losses.

The device operates reliably across a wide temperature range from -55°C to 125°C, making it suitable for demanding industrial and automotive applications. The maximum self-resonant frequency of 25 MHz allows usage in high-frequency circuits. It is terminated with surface mount style leads for quick and efficient PCB assembly processes. This inductor is wholly RoHS and JEDEC compliant, reflecting Vishay’s commitment to quality and environmental standards.

This series is designed for applications requiring high transient current handling without saturation and ultra-low buzz noise, such as power supplies for PDAs, notebooks, desktops, servers, and field programmable gate arrays (FPGAs). It is particularly suited for high current point-of-load (POL) converters, low profile power supplies, DC/DC converters, and battery-powered devices in distributed power systems.

Engineers and industrial manufacturers can integrate this high-performance shielded inductor into complex electronic circuits where size, performance, and suppression of electromagnetic interference are critical. The product comes supplied on reels, ready for automated assembly line insertion, enhancing manufacturing efficiency.

Utilizes a metal composite core for high performance. Compact 2020 package with dimensions 5.49mm length, 5.18mm depth, and 3mm height. Low DC resistance of 77.5 mΩ increases energy efficiency. Wide operating temperature range from -55°C to 125°C.

Magnetically shielded wire wound design minimizes EMI and noise. Handles high transient current spikes without saturation. Maximum self-resonant frequency of 25 MHz for high frequency operation. Surface mount termination style ensures PCB assembly compatibility.

RoHS and JEDEC approved for quality and environmental compliance. Suitable for PDAs, notebooks, servers, FPGAs, and power supply circuits. Discover more Surface Mount Inductors and electronic components with Vishay products at EnvMart for your industrial, electrical, and lab applications.
