ams OSRAM 3.2 V Green LED SMT Surface Mount DURIS S5 GT PSLM31.13-HPHR-45-1

Name: ams OSRAM 3.2 V Green LED SMT Surface Mount DURIS S5 GT PSLM31.13-HPHR-45-1
Brand: ams OSRAM
SKU: 390780
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand ams OSRAM Condition New

Specifications

Country of Origin	China
Brand	ams OSRAM
Colour	528 nm ( true green )
Package	white SMT package, colourless clear resin
Model	GT PSLM31.13-HPHR-45-1
Packaging	12 mm Tape with 3000 pcs on Dia 180 mm Reel
Mount Type	Surface
Series	DURIS S5
Luminous Flux	typ. 35.6 lm
Maximum forward current	200mA
Viewing angle	120 °
Package Type	SMT
Standards/Approvals	JEDEC J-STD-020E, IEC 62471:2008, ANSI/IES LM-80-15
LED Colour	Green
Dominant Wavelength	543nm
Forward Voltage	3.2V
Number of Pins	2
Lens Dimensions	3 x 3 x 0.6 mm
Lens Shape	Square
LED Luminous Flux	33 to 41.9 lm
Luminous Efficacy	typ. 123 lm/W
Viewing angle at 50 % IV	120°
Standards/ApprovalsJEDEC J-STD-020E, IEC 62471	2008, ANSI/IES LM-80-15

Key Features

This LED provides a green color emission with a dominant wavelength of 543 nm.
Maximum forward current is 200 mA ensuring efficient operation.
Packaged in a white SMT package with colorless clear resin and a 12 mm tape with 3000 units per reel.
Features a viewing angle of 120 degrees, delivering broad light dispersion.
Lens dimensions are 3 x 3 x 0.6 mm with a square lens shape and clear finish.
Luminous flux ranges from 33 to 41.9 lumens, with a typical luminous flux of 35.6 lm.
Luminous efficacy is typically 123 lm/W, providing high brightness per watt.
Designed for applications such as architectural lighting, smart lighting, and cove lighting.

Product Description

The ams OSRAM GT PSLM31.13-HPHR-45-1 is a high-performance green light-emitting diode (LED) designed for surface-mount technology (SMT) applications, featuring the DURIS S5 series package. Operating with a forward voltage of 3.2 V and a maximum forward current rating of 200 mA, this SMT LED delivers a vibrant green light emission with a dominant wavelength of 543 nm, typical of true green color tones.

This LED’s white SMT package includes a colorless clear resin encapsulation and is supplied on a 12 mm tape reel containing 3000 units, facilitating efficient automated assembly processes. Designed with a viewing angle of 120 degrees and a square lens measuring 3 x 3 x 0.6 mm, it ensures a broad and uniform light distribution. The clear lens finish enhances optical clarity and output.

With luminous flux values ranging from 33 to 41.9 lumens and a typical luminous flux of 35.6 lm, this component achieves a luminous efficacy of approximately 123 lm/W, making it energy-efficient with bright output. Its high-quality construction adheres to industry standards including JEDEC J-STD-020E for moisture sensitivity, IEC 62471:2008 for photobiological safety, and ANSI/IES LM-80-15 for lumen maintenance testing.

This LED is suitable for diverse lighting uses such as architectural lighting features, smart lighting systems, and cove lighting installations, offering reliable and consistent green illumination. Its surface mount configuration aligns well with compact modern electronic designs requiring robust light sources.

Green color LED with dominant wavelength 543 nm. Maximum forward current: 200 mA. Packaged in white SMT package with colorless clear resin. Supplied on 12 mm tape reel of 3000 pcs for automated mounting. Wide 120° viewing angle for broad light dispersion.

Lens dimensions: 3 x 3 x 0.6 mm, square shape, clear lens finish. Luminous flux typical 35.6 lm with luminous efficacy of 123 lm/W. Compliant with JEDEC J-STD-020E, IEC 62471:2008, ANSI/IES LM-80-15. Ideal for architectural, smart, and cove lighting applications.

Explore the comprehensive range of ams OSRAM LEDs at EnvMart for robust and efficient illumination solutions.

Explore more products in our Electronic Components, Power & Connectors category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The dominant wavelength of this green LED is 543 nm, which is characteristic of true green color tones.

The maximum forward current for this model is 200 mA, ensuring efficient operation.

The lens dimensions for this LED are 3 x 3 x 0.6 mm, and it has a square shape with a clear finish.

The luminous flux for this LED ranges from 33 to 41.9 lumens, with a typical value of 35.6 lumens.

It is packaged in a white SMT package with a colorless clear resin, supplied on a 12 mm tape reel containing 3000 units.

The luminous efficacy of this LED is typically 123 lm/W, indicating its energy efficiency.

This LED complies with JEDEC J-STD-020E for moisture sensitivity, IEC 62471:2008 for photobiological safety, and ANSI/IES LM-80-15 for lumen maintenance testing.

The forward voltage for this LED is 3.2 V, which is necessary for its operation.

This LED is suitable for applications such as architectural lighting, smart lighting systems, and cove lighting installations.

This LED has 2 pins, which are typical for surface mount technology components.

This LED belongs to the DURIS S5 series, which is designed for high-performance SMT applications.
