onsemi Operational Amplifier 7 MHz, 14-Pin SOIC, 5.5V, Quad Channel NCS20034DR2G

onsemi NCS20034DR2G operational amplifier is a high-performance quad channel device featuring a 7 MHz gain bandwidth product and a high slew rate of 8 V/µs. Packaged in a 14-pin SOIC, it supports low voltage operation from 1.8 V up to 5.5 V, making it suitable for a variety of portable and low-power electronic applications.

The device ensures precise analog signal amplification with a low input offset voltage of 5 mV and ultra-low input bias and offset currents (1 pA), ideal for current shunt monitoring and high accuracy analog front ends. The rail-to-rail output stage maximizes the output voltage swing, improving signal fidelity in battery-powered and rail-to-rail input systems.

Engineered to meet the stringent automotive AEC-Q100 standard, this amplifier provides robust operation across an extended temperature range spanning from -40°C to 85°C. Compact dimensions (1.5 mm height, 8.75 mm length, 4 mm width) allow for dense PCB layout designs in space-critical applications.

The output current capability of 8 mA supports driving moderately low impedance loads, suitable for embedded control electronics and sensor interface circuits. Its RoHS compliance aligns with environmental regulations for sustainable device manufacturing.

High slew rate of 8 V/µs for rapid response. Wide supply voltage range: 1.8 V to 5.5 V. Four amplifier channels in a single package. Low input offset voltage and bias currents for precision. Automotive-qualified to AEC-Q100 standard.

Compact SOIC package footprint for circuit integration. Extended operating temperature range for reliability. Rail-to-rail output drive capability for maximum signal swing. RoHS compliant to support environmentally friendly manufacturing.

Suitable for portable electronics, industrial, automotive and instrumentation applications.

This operational amplifier from onsemi is well suited for industrial, automotive, portable electronics, instrumentation, and general purpose applications where low power consumption, high precision, and robust performance are required. Its array of features supports efficient analog signal conditioning in embedded system designs.

For additional design resources, users can access datasheets, RoHS certificates, and related technical documentation. This product exemplifies the quality and reliability expected of onsemi semiconductor components.
