Europa Miniature Circuit Breaker 3-Pole 1A Type C 400V AC 10 kA Breaking Capacity EUC3P

The Europa EUC3P Miniature Circuit Breaker, model EUC3P, is a 3-pole device rated at 1 ampere with a Type C tripping characteristic. It operates at 400V AC and features a breaking capacity of 10kA, making it highly reliable for electrical safety in industrial, commercial, and residential electrical distribution systems.

This MCB is suitable for mounting on standard 35mm DIN rails (mount type DIN Rail) ensuring typical integration into electrical panels and consumer units. It has an IP20 protection rating which safeguards against ingress of solid foreign objects, making it ideal for indoor applications.

With a compact design measuring 78mm in width, 54mm in height, and 87mm in depth, it offers space-saving installation without compromising robustness. The tunnel terminal type accommodates wiring from 1mm² up to 25mm², supporting flexible circuit connections. The toggle switch actuator provides straightforward manual reset functionality.

The device complies with widely recognized international safety and quality standards including IEC 60898 and EN 60898, certified by SEMKO and CE, affirming the product’s conformity for safe use. This miniature circuit breaker is produced in China and designed to deliver dependable circuit protection with fast response during overloads or short circuits.

Industries such as manufacturing, electrical automation, commercial buildings, and infrastructure benefit from the compact size, reliable performance, and ease of use. Its 10kA breaking capacity ensures the device can interrupt fault currents safely, preventing damage to electrical equipment.

This circuit breaker features a current rating of 1 ampere. It operates within a rated AC voltage of 400 volts. The tripping characteristic is Type C, suitable for general purpose protection. It has a breaking capacity of 10 kiloamperes, ensuring safety during faults.

The breaker is mounted on a 35mm DIN rail for easy installation. Its IP20 rating provides protection against solid foreign objects. Dimensions are 78mm width, 54mm height, and 87mm depth for compact fitting. The terminal type is tunnel with capacity ranging from 1mm² to 25mm² wires.

The reset actuator is a toggle switch, allowing user-friendly operation. It conforms to international standards IEC 60898 and EN 60898 with SEMKO and CE approvals. Explore more Miniature Circuit Breakers and circuit protection solutions in the Electronics & Electricals category at EnvMart for reliable safety and high-quality standards.
