Europa Miniature Circuit Breaker, 3-Pole, 32A, Type C, 400V AC, 10 kA Breaking Capacity EUC3P

Free Delivery in India | Lowest Global Shipping Charges

Europa Miniature Circuit Breaker, 3-Pole, 32A, Type C, 400V AC, 10 kA Breaking Capacity EUC3P

Name: Europa Miniature Circuit Breaker, 3-Pole, 32A, Type C, 400V AC, 10 kA Breaking Capacity EUC3P
Brand: Europa
SKU: 381808
Price: 35.65 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Europa Condition New

Specifications

Country of Origin	China
Range	EUC3P
Brand	Europa
Height	54mm
Model	EUC3P
Depth	87mm
IP Rating	IP20
Width	78mm
Mount Type	DIN Rail
Current Rating	32A
Terminal Capacity	1mm2 to 25mm2
Series	EUC3P
Terminal type	Tunnel
Breaking Capacity	10kA
Number of Poles	3
Standards/Approvals	CE, EN 60898, SEMKO, IEC 60898
Rated AC Voltage	400V ac
Tripping Characteristics	Type C
Reset Actuator Type	Toggle Switch

Key Features

Suitable for consumer units with DIN rail mounting compatibility.
Complies with IEC 60898 and EN 60898 standards ensuring reliable circuit protection.
Features a toggle switch reset actuator for easy operation.
Terminal type is tunnel with capacity ranging from 1mm2 to 25mm2.
Compact dimensions of 78mm width, 54mm height, and 87mm depth.
IP20 rated for dust protection in typical electrical environments.
Operating temperature range from -5° to 40°C for varied conditions.
Manufactured in China under CE and SEMKO approvals.

Product Description

Europa EUC3P Miniature Circuit Breaker (MCB) model EUC3P is a robust and reliable 3-pole electrical protection device rated at 32A current carrying capacity. It is designed for 400V AC systems and offers a breaking capacity of 10 kA, suitable for industrial, commercial, and residential applications requiring effective overcurrent protection.

This MCB features a Type C tripping characteristic that provides protection against moderate inrush currents common in inductive loads such as motors and transformers. The toggle switch actuator ensures quick and easy manual reset after a trip.

Mountable on a standard 35mm DIN rail, the EUC3P MCB integrates seamlessly into consumer units or distribution boards. The tunnel-type terminals support conductor sizes from 1mm² up to 25mm², facilitating flexible wiring options.

Compact and space-saving, the device measures 78mm in width, 54mm in height, and 87mm in depth. Its IP20 rating offers protection against solid objects and inadvertent finger contact, making it suitable for controlled electrical panel environments.

Operating reliably in ambient temperatures from -5° to 40°C, this breaker benefits from CE and SEMKO certifications and conforms to the IEC 60898 and EN 60898 standards ensuring safety and quality assurance.

The UEU3P MCB is manufactured in China and is ideal for applications in industrial automation, power distribution, electrical safety systems, HVAC installations, and building wiring systems.

Suitable for consumer units with DIN rail mounting compatibility. Complies with IEC 60898 and EN 60898 standards ensuring reliable circuit protection. Features a toggle switch reset actuator for easy operation. Terminal type is tunnel with capacity ranging from 1mm2 to 25mm2.

Compact dimensions of 78mm width, 54mm height, and 87mm depth. IP20 rated for dust protection in typical electrical environments. Operating temperature range from -5° to 40°C for varied conditions. Manufactured in China under CE and SEMKO approvals.
