| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 2.7mm |
| Model | PDZ9.1B,115 |
| Mount Type | Surface |
| Series | PDZ-B |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Standards/Approvals | EU/CN RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 400mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 500nA |
| Nominal Zener Voltage Vz | 9.1V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 10Ω |
| Typical Voltage Temperature Coefficient | 5.5mV/K |
| Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand | DiodesZetex |
Nexperia PDZ9.1B,115 is a single Zener diode designed as a voltage regulator with a nominal Zener voltage of 9.1 V and a power dissipation rating of 400 mW. Packaged in a small plastic SOD-323 surface mount device with 2 pins, it is suitable for compact and efficient PCB assembly in various electronics applications.
This Zener diode offers tight voltage regulation with a tolerance of ±2% and operates with a low maximum reverse leakage current of 500 nA, making it ideal for low-power voltage reference and protective circuitry. Its maximum Zener impedance of 10 Ω and test current of 5 mA ensure stable and reliable voltage clamping in sensitive electronic circuits.
The diode maintains performance across a broad temperature range, enabled by a typical voltage temperature coefficient of 5.5 mV/K and a maximum operating temperature of 150°C, meeting automotive standard AEC-Q101 and RoHS environmental regulations.
The compact size with dimensions of 2.7 mm length and 1.1 mm height facilitates integration into space-constrained electronic devices and industrial control systems. Single element diode for voltage regulation. SMD package type SOD-323 for surface mounting.
Nominal Zener voltage: 9.1 V with ±2% tolerance. Maximum power dissipation: 400 mW. Low reverse leakage current and impedance for efficient operation. Automotive standard compliant and RoHS certified.
This Nexperia PDZ9.1B,115 Zener Diode is widely used in electronic component manufacturing, automotive electronics, instrumentation, and consumer electronics for voltage stabilization and surge protection. Its robust specs and compact form factor ensure dependable performance in harsh industrial, automotive, and consumer environments.
Explore the full range of Nexperia semiconductors and discrete components on EnvMart for professional electronics design and manufacturing solutions.
