onsemi Operational Amplifier 24 MHz, 8-Pin SOIC, Dual Channel, 3-36V NCV33272ADR2G

onsemi's NCV33272ADR2G is a precision dual operational amplifier designed for high-speed and low noise signal processing applications. Featuring a 24 MHz gain bandwidth product and a high slew rate of 10 V/μs, this amplifier addresses demanding industrial, automotive, and electronic design requirements within a compact 8-Pin SOIC surface mount package.

This device operates reliably across a wide voltage range between 3V and 36V, supporting robust performance in applications with varied supply conditions. Its low input offset voltage trimmed to 100 μV typical, along with low input bias currents down to 300 nA, ensures precise analog signal amplification with minimal distortion.

The NCV33272ADR2G employs advanced bipolar input technology and patented Zip-R-Trim adjustment to maintain low input offset voltage and noise, making it ideal for instrumentation, sensor signal conditioning, and audio amplification tasks.

Its robust design meets automotive AEC-Q100 quality standards and RoHS directives, qualifying it for high-reliability contexts such as automotive electronics and industrial control systems. The device supports operation over a temperature range of -40°C to +125°C, ensuring durability in harsh environments.

Compact physical dimensions of 5 mm length, 4 mm width, and 1.5 mm height facilitate compact PCB layouts. With an output current capacity of 37 mA, it can effectively drive loads in typical analog circuits. This makes it suitable for applications in electronics manufacturing, industrial automation, communications, and automotive sensor systems.

High gain bandwidth product of 24 MHz suitable for fast signal amplification. Dual channel operational amplifier with 8-pin SOIC surface mount package. Wide supply voltage range from 3V minimum to 36V maximum. Low input offset voltage trimmed to 100 μV typical for precision applications.

High slew rate of 10 V/μs for rapid output transitions. Low input bias and offset currents for minimal signal distortion. Robust operating temperature range from -40°C to +125°C for industrial usage. Complies with RoHS standards and automotive AEC-Q100 qualification.

Compact dimensions: 5mm length, 4mm width, and 1.5mm height for space-efficient PCB designs. Output current capability of 37 mA to drive various loads effectively.

This operational amplifier is ideal for use in industrial, automotive, laboratory, and manufacturing electronics, providing precise and stable analog signal amplification. Explore more Operational Amplifiers and semiconductor components within the onsemi range at EnvMart for your next electronics project.
