TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 1 μH ±10% 50 A Idc ERU20

TDK ERU20 Shielded Wirewound Surface Mount Inductor model B82559A2102A020 offers a 1 μH inductance with ±10% tolerance and supports a maximum DC current of 50 A. This wirewound component utilizes a ferrite core with magnetic shielding to provide high stability and efficiency in high-frequency applications.

Specifically designed for surface mount applications, it comes in an ERU20 package casing, compatible with automated PCB assembly techniques. Its low DC resistance of 620 μΩ enhances energy efficiency by minimizing power loss during operation. The component is qualified under the AEC-Q200 standard, making it suitable for automotive and other high-reliability environments. The operating temperature range from -40°C to 150°C ensures stable performance under harsh conditions.

The inductor exhibits a maximum self-resonant frequency of 2 MHz, making it suitable for DC-DC converters, POL converters, VRM modules, and solar power converters. Being RoHS compliant, it aligns with environmental regulations. Packaging uses tape and reel format, optimized for mass production.

Mechanical dimensions include a length of 21.5 mm, height of 9.8 mm, and depth of 21 mm, with a surface mount termination style to facilitate soldering on PCBs. Its wirewound construction and ferrite core provide excellent inductive properties and magnetic shielding, reducing interference and enhancing circuit stability.

Constructed with ferrite core and wirewound design ensuring magnetic shielding and high performance. Low DC resistance of 620 μΩ for efficient current handling. Complies with automotive standard AEC-Q200 for enhanced reliability.

Maximum DC current rating of 50 A supports high power applications. Operating temperature range from -40°C to 150°C allows use in diverse environments. Maximum self-resonant frequency of 2 MHz. Packaged on tape and reel format for automated assembly.

Dimensions: 21.5 mm length, 9.8 mm height, 21 mm depth.

This TDK ERU20 series inductor is ideal for use in industrial electronics, automotive power modules, solar converters, and manufacturing of high-frequency devices. It combines high performance with durability, meeting the strict standards required for professional electronics design and production.
