Wurth Elektronik WE-MAPI 3015 Wirewound Surface Mount Inductor Composite Iron Powder Core 3.3 μH ±20 % 74438335033

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-MAPI 3015 Wirewound Surface Mount Inductor Composite Iron Powder Core 3.3 μH ±20 % 74438335033

Name: Wurth Elektronik WE-MAPI 3015 Wirewound Surface Mount Inductor Composite Iron Powder Core 3.3 μH ±20 % 74438335033
Brand: Wurth Elektronik
SKU: 371494
Price: 1.55 USD
Availability: InStock



Category Surface Mount Inductor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Korea
Brand	Wurth Elektronik
Height	1.5mm
Length	3mm
Depth	3mm
Packaging	Tape & Reel
Series	WE-MAPI
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Composite Iron Powder
Inductance	3.3μH
Standards/Approvals	IPC/JEDEC J-STD-020D
Package/Case	3015
Maximum DC Current	1.7A
Maximum DC Resistance	131mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	35MHz
Inductor Construction	Moulded
Automotive Standard	AEC-Q200

Key Features

Compact 3015 package size with 3 mm length, 3 mm depth, and 1.5 mm height dimensions.
Constructed with a composite iron powder core, providing magnetic shielding and reduced leakage flux noise.
Rated for maximum DC current of 1.7 A and maximum DC resistance of 131 mΩ.
Operates reliably within -40°C to 125°C temperature range, meeting automotive standard AEC-Q200.
Features a moulded inductor construction with a surface mount termination style.
Handles frequencies up to a maximum self-resonant frequency of 35 MHz.
Complies with IPC/JEDEC J-STD-020D standards for surface mount components.

Product Description

Wurth Elektronik 74438335033 WE-MAPI series wirewound surface mount inductor offers a 3.3 μH inductance with ±20 % tolerance, designed with a composite iron powder core for superior magnetic shielding. This 3015 moulded inductor package provides compact dimensions of 3 mm length, 1.5 mm height, and 3 mm depth, suitable for high-density PCB designs.

Its magnetic iron alloy construction enables it to handle high transient current spikes and sustain a maximum DC current of 1.7 A with low DC resistance of 131 mΩ. The inductor operates efficiently within a wide temperature range of -40°C to 125°C and complies with the automotive standard AEC-Q200, underscoring its reliability in automotive and industrial applications.

The surface mount termination style ensures easy automated assembly, enhancing production efficiency. It supports frequencies up to 35 MHz with a maximum self-resonant frequency, suitable for high-frequency DC/DC converters, POL converters, and FPGA power supply circuits.

Applications include high current power supplies, portable devices such as PDAs and digital cameras, mainboards, graphic cards, and wireless communication devices. Its shielded construction minimizes acoustic and leakage flux noise, beneficial in noise-sensitive electronics.

Compact 3015 case size with magnetic shielding and composite iron powder core. Designed for high transient current capacity and low acoustic noise operation. Suitable for automotive and industrial electronic power management circuits.

Compliance with IPC/JEDEC J-STD-020D standards for surface mount technology ensures durability. Ideal for use in smart phones, tablets, and other mobile device power supplies. Tape and reel packaging enables efficient production line assembly.

Choose the Wurth Elektronik WE-MAPI 74438335033 inductor for reliable, compact, and high performance power inductors suitable for advanced electronic, automotive, and industrial applications. Explore more power inductors in the Surface Mount Inductors category on EnvMart.
