STMicroelectronics Schottky Diode 200 V 10 A Surface Mount DO-214AA Package STPS2200U

STMicroelectronics STPS2200U is a high-performance Schottky diode designed for demanding electronic applications requiring efficient rectification and low forward voltage drop. This diode features a peak reverse repetitive voltage of 200 V and supports a maximum continuous forward current of 10 A, making it suitable for robust power management tasks in various industrial, automotive, and consumer electronics contexts.

Housed in a DO-214AA surface-mount package, the STPS2200U provides reliable mechanical stability with compact dimensions conducive to modern PCB layouts. The diode delivers excellent surge current capability with a peak non-repetitive forward surge current of 100 A, ensuring resilience during transient events and startup conditions.

The diode operates efficiently within a wide temperature range, from -40°C to 175°C, permitting use in harsh environments and industrial settings. It has a low maximum forward voltage of 0.58 V, which helps reduce power dissipation and improves overall energy efficiency.

Applications include power supplies, voltage clamping, freewheeling diodes in motor drives, and switching power converters. The STPS2200U’s low leakage current and fast switching characteristics make it well suited for high-frequency circuits and semiconductor-based power electronics.

Compact 2-pin surface mount package ensures easy board assembly. Supports high continuous forward current of 10 A for demanding loads. High peak reverse voltage rating of 200 V provides voltage safety margins. Efficient low forward voltage of 0.58 V enhances power saving.

Wide operating temperature range for extended reliability. High surge current tolerance for transient protection. Small footprint optimizes PCB space usage.

This diode is an excellent choice for designers needing robust, efficient, and compact Schottky barrier rectifiers. It finds extensive use in industrial electronic assemblies, automotive electronics, power adapters, and general semiconductor-based power regulation circuits.
