Nexperia 1 2-Input OR Logic Gate 5-Pin TSSOP 74HC1G32GW,125

Nexperia 74HC1G32GW,125 1 2-Input OR Logic Gate is a high-speed CMOS logic integrated circuit designed for efficient logic operations in electronic and industrial applications. This component is housed in a 5-pin TSSOP surface mount package, making it ideal for compact printed circuit boards where space conservation is essential.

The logic gate operates within a wide supply voltage range of 2 to 6 volts, supporting minimum operating temperature of -40°C and maximum of 125°C, which makes it suitable for a broad spectrum of environmental conditions including industrial and automotive environments. It features a maximum propagation delay of 23 nanoseconds, ensuring rapid signal response for real-time processing tasks.

Designed for CMOS input and output compatibility, the device ensures low power consumption and high noise immunity, characteristics essential for modern electronic systems including communication equipment, automation systems, and consumer electronics.

The device's dimensions of 2.25 mm in length and 1 mm in height provide compactness without compromising functionality. The 74HC1G32GW,125 belongs to the 74HC family, trusted for its high speed and reliability in logic gate applications.

Typical use cases include electronic circuit design, signal processing, embedded system modules, and industrial control systems. Availability in a single logic element per package simplifies the design process of OR logic functions.

Key features of the Nexperia 74HC1G32GW,125 include surface mount convenience, 2-input OR logic function, CMOS compatibility, and broad temperature and voltage adaptability. Operates at a voltage range of 2 to 6 V for versatile application.

Features a maximum propagation delay time of 23 ns, enabling fast signal processing. Designed for surface mount with a 5-pin TSSOP package to save PCB space. Supports 2 inputs per gate with a high level output current of -2.6 mA and low level output current of 2.6 mA.

Military-grade operating temperature range from -40°C to 125°C ensures reliable performance in harsh environments. CMOS input and output compatibility for seamless integration with other logic circuits. Compact dimensions of 2.25 mm length and 1 mm height allow for dense board layouts.

Manufactured in Malaysia under the 74HC family series, known for high-speed logic operations. Package includes a 1-element logic gate facilitating simple or logic function deployment. Explore the range of Nexperia Logic Gates and other semiconductor products at EnvMart for high quality and reliability in your electronic design projects.
