TDK 0805 MLF Series Shielded Multilayer Surface Mount Inductor, Ferrite Core, 680 nH ±10% 150 mA Idc Q:25 MLF2012DR68KT000

TDK MLF2012DR68KT000 is a shielded multilayer surface mount inductor in the 0805 package size, featuring a ferrite core with an inductance of 680 nH and a tolerance of ±10%. This component supports a maximum DC current of 150 mA and maintains a quality factor (Q) of 25, making it suited for various electronic circuit applications requiring compact, reliable inductance.

The shielded magnetic construction reduces electromagnetic interference (EMI), which is vital in sensitive electronics such as digital cellular phones, tuners, personal computers, and audio devices. Its multilayer monolithic design ensures high reliability and excellent heat resistance, suitable for flow and reflow soldering, including lead-free processes.

This inductor operates efficiently within a temperature range of −40°C to 85°C, making it robust for diverse environmental conditions. The 0805 package measures 2 mm in length with a height and depth of 1.25 mm each, supporting surface mounting via its dedicated termination style. Maximum DC resistance is limited to 600 mΩ to keep power losses low.

Key technical details include compliance with RoHS standards, ensuring environmentally responsible manufacturing and usage. Its ferrite core material improves inductance performance and reduces losses. The multilayer construction further enhances component stability and effectiveness in high-frequency applications, with a maximum self-resonant frequency of 190 MHz facilitating use in advanced circuits.

Magnetic shielding effectively minimizes EMI for sensitive electronics. High reliability due to monolithic multilayer design with ferrite core. Compact 0805 package suitable for surface mount technology. Robust operation across temperature range from −40°C to 85°C.

Low DC resistance of 600 mΩ reduces power loss in circuits. RoHS compliant ensuring environmental safety and regulatory adherence. Applicable in devices like mobile phones, tuners, and audio equipment. Supports assembly processes including lead-free reflow soldering.

High quality factor of 25 improves signal integrity and performance. Maximum self-resonant frequency of 190 MHz suitable for high-frequency circuits.
