onsemi Operational Amplifier 4.5 MHz Gain Bandwidth, 4 Channels, 14-Pin SOIC, 44V MC33074DR2G

onsemi MC33074DR2G is a new, surface-mount operational amplifier suitable for high-performance analog signal processing requiring four channels in a single 14-pin SOIC package. It offers a gain bandwidth product of 4.5 MHz and supports an operating voltage range from 3 V to 44 V.

This quad operational amplifier features a high slew rate of 13 V/μs ensuring fast transient response and low input offset voltage, improving the accuracy of signal amplification in precision electronics. The input bias current is minimal, facilitating applications requiring low input current drift.

The device is designed for robust performance with output current capability of 30 mA, large output voltage swing, and the ability to drive large capacitive loads up to 10000 pF. It complies with RoHS and automotive standard AEC-Q100, making it suitable for demanding automotive and industrial environments.

Key operational characteristics include a fast settling time of 1.1 μs to 0.1%, wide input common mode voltage range including ground, and excellent harmonic distortion performance, making it ideal for instrumentation, control systems, and audio applications.

The MC33074 series supports single and split supply configurations and is packaged to optimize PCB space with a compact 1.5 mm height, 8.75 mm length, and 4 mm width footprint. Wide single supply operation from 3 V to 44 V.

Fast slew rate of 13 V/μs ensuring swift analog response. Low input offset voltage and bias current for precision amplification. High output current drive capability of 30 mA for varied load conditions. Automotive standard AEC-Q100 compliance for reliability.

RoHS compliant for eco-friendly design standards. Large capacitive drive capability up to 10000 pF. Fast settling time of 1.1 μs to 0.1% accuracy. Compact SOIC 14-pin surface mount package dimensions.

This Operational Amplifier is extensively used in industrial, automotive, instrumentation, audio, and control system applications. Designed for manufacturers and engineers requiring a robust, high-speed, multi-channel analog solution, it integrates well into printed circuit boards requiring surface-mount technology.
