Eaton 0703 Shielded Wirewound Surface Mount Inductor 6.8 μH ±20 % 3.12 A IDC Ferrite Core DR73-6R8-R

Eaton DR73-6R8-R 0703 Shielded Wirewound Surface Mount Inductor with a ferrite core provides an inductance of 6.8 μH and supports a maximum DC current of 3.12 A. This wirewound inductor is designed with magnetic shielding to enhance electrical performance and reduce interference, making it ideal for modern electronic applications.

Constructed for surface mount technology (SMT), the 0703 package ensures compact placement on PCBs with a length of 7.6 mm, height of 3.55 mm, and depth of 7.6 mm. The device operates reliably in temperatures ranging from -40°C to 125°C, suitable for demanding industrial and consumer electronics environments.

Its ferrite core construction supports a maximum self-resonant frequency of 100 kHz, optimizing it for filtering and power conversion tasks. The ±20% inductance tolerance provides flexibility across a variety of electronic circuits. The inductor is molded to ensure mechanical stability and high reliability in assembly.

Applications include noise filtering, buck and boost converters, forward and resonant converters, computer hardware, DVD players, LCD panels, and other portable devices requiring efficient electromagnetic interference suppression.

This RoHS-compliant inductor is manufactured in China and features a surface-mount termination style for automated assembly processes. Eaton's DR series offers durable, high-efficiency magnetic components for industrial, laboratory, manufacturing, and commercial electronics use cases.

The inductor features a ferrite core for enhanced magnetic performance. Constructed with wirewound technology for reliability and efficiency. Package size is 0703 with a compact length of 7.6 mm and height of 3.55 mm. Inductance tolerance is ±20 %, suitable for various electronic applications.

Maximum operating temperature rated at 125°C ensures durability in demanding conditions. Shielding is included to minimize electromagnetic interference. Terminated with surface mount style for easy PCB integration. Meets RoHS standards, assuring compliance with environmental regulations.

Maximum DC resistance is 43.5 mΩ contributing to low power loss. Designed for use in noise filtering, DC-DC converters, and portable electronic devices. Explore the Electronics & Electricals category on EnvMart to find a broad range of inductors and surface mount components from leading brands like Eaton.
