Samtec SQT Series Right Angle Through Hole PCB Socket 10-Contact 2 Row 2 mm Pitch Solder SQT-105-01-L-D-RA

Free Delivery in India | Lowest Global Shipping Charges

Samtec SQT Series Right Angle Through Hole PCB Socket 10-Contact 2 Row 2 mm Pitch Solder SQT-105-01-L-D-RA

Name: Samtec SQT Series Right Angle Through Hole PCB Socket 10-Contact 2 Row 2 mm Pitch Solder SQT-105-01-L-D-RA
Brand: Samtec
SKU: 366834
Price: 2.98 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	450V
Brand	Samtec
Orientation	Right Angle
Current	5.5A
Temperature range	-55 → 125 °C
Model	SQT-105-01-L-D-RA
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Bronze
Current Rating	5.5 A at 20 °C
Series	SQT
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Female
Connector System	Board-to-Board
Insulator Material	Black LCP
SQT-1xx-01-L-S	single row vertical
SQT-1xx-01-L-x-RA	horizontal
SQT-1xx-01-L-D	double row vertical

Key Features

Features 0.5 mm square tiger buy contacts plated with 0.25 μm gold on the contact area.
PCB tails have matte tin plating ensuring reliable solder connections.
Housing is made of black liquid crystal polymer (LCP), offering durability and insulation.
Rated for a current of 5.5 A at 20 °C and a voltage of 450 V.
Operating temperature range spans from -55 °C to 125 °C for broad industrial use.
Connector system supports board-to-board connections with right angle orientation.
Termination type is solder through hole for robust assembly.
Post length measures 2.29 mm and above board height is 6.35 mm.

Product Description

Samtec SQT-105-01-L-D-RA is a high-quality 10-contact, 2-row right angle through hole PCB socket with 2 mm pitch. Designed for reliable board-to-board connectivity, it features rugged construction and precision contacts.

The connector uses tiger buy 0.5 mm square contacts that are gold plated with 0.25 μm thickness, ensuring low contact resistance and optimal signal transmission. Its PCB tails feature matte tin plating for excellent solderability.

Constructed with black liquid crystal polymer (LCP) housing, the socket offers excellent insulation and mechanical stability across a wide temperature range of -55 °C to 125 °C, making it suitable for demanding industrial and electronic applications.

Electrical specifications include a current rating of 5.5 A at 20 °C and working voltage up to 450 V, enabling it to handle moderate power levels efficiently. The right angle orientation facilitates compact PCB designs in board-to-board connector systems.

The SQT-105-01-L-D-RA variant is a double row vertical socket with through hole solder termination, providing robust mechanical fixation. Contact gender is female with bronze material and gold plating to ensure reliable electrical connection.

Features 10 contacts arranged in 2 rows with 2 mm pitch. Post length of 2.29 mm and above board height of 6.35 mm. Insulator material is black LCP for durability and electrical insulation. Temperature range: -55 °C to 125 °C for industrial uses.

Current rating of 5.5 A at 20 °C, voltage rating up to 450 V. Solder termination type with through hole mounting. Right angle orientation suitable for board-to-board connector systems. Contact plating with 0.25 μm gold on bronze base enhances conductivity.

This PCB socket is ideal for industrial, electronic components manufacturing, power connectors assembly, and various commercial electronic equipment where reliable, rugged board-to-board connections are required.

Explore more PCB socket and connector options within the Samtec SQT Series on EnvMart for your industrial and manufacturing needs.

Explore more products in our PCB Sockets category.
